Page 1: User Manual
Internet Phone Wizard Model #: UP101 User Manual Solutions for the Digital Life ™... -
Page 2: Table Of Contents
Table of Contents 1 Introduction Package Contents Features System Requirements Getting to Know the Internet Phone Wizard Technical Support 2 Installing Skype™ Software Downloading and Installing Skype Creating a Skype Account Adding Accounts Assign a Speed-Dial Number 3 Connecting the Internet Phone Wizard Hardware Single Line Connection Dual Line Connection... - Page 3 Actiontec Internet Phone Wizard User Manual This page left intentionally blank.
-
Page 4: Introduction
If you want to take your communications to the next level, and save money while doing it, the Actiontec Internet Phone Wizard is sure to be one of the keys to your success. -
Page 5: Features
Actiontec Internet Phone Wizard User Manual Features Excellent voice quality Low international calling rates Works with Skype Easily switch between regular (analog) and Internet phone modes Call waiting and ringback operations supported No special settings or configuration for use with firewall... -
Page 6: Getting To Know The Internet Phone Wizard
Getting to Know the Internet Phone Wizard This section contains a quick description of the Internet Phone Wizard’s lights and ports. The Internet Phone Wizard has several indicator lights ( panel and a series of ports on its rear panel. Front Panel The front panel of the Internet Phone Wizard features three lights: Regular Call, Internet Call, and Ready. -
Page 7: Technical Support
The Phone port is used to connect the Internet Phone Wizard to a telephone via phone cable. Technical Support Actiontec Electronics prides itself on making durable, high-quality, high-perfor- mance products. If you need assistance, the Actiontec Technical Support Department is available all day every day to provide professional support. E-mail: http://support.actiontec.com/email_support/support_form.php Internet: www.actiontec.com/support Actiontec Electronics, Inc. -
Page 8: Installing Skype™ Software
Installing Skype™ Software The first step in setting up the Internet Phone Wizard is installing Skype on the computer. This chapter describes the Skype installation procedure in four parts: downloading and installing Skype, creating an account, adding contacts, and assigning speed-dial numbers. Downloading and Installing Skype If Skype has already been installed on the computer, make sure it is the latest ver- sion. - Page 9 Actiontec Internet Phone Wizard User Manual 4. In the window that appears, select a language, then click OK. 5. The “Skype Setup Wizard” appears. Read the on-screen instructions, then click Next. 6. In the next window, click in the circle next to “I accept the agreement,” then...
- Page 10 Chapter 2 Installing Skype 7. Select a location on the computer’s hard drive to download the Skype soft- ware, then click Next. 8. In the next window, set up additional tasks, if needed, then click Next.
-
Page 11: Creating A Skype Account
Actiontec Internet Phone Wizard User Manual 9. Skype installs. Click Finish in the last window to complete the installation. The Skype software is installed on the computer. Go to the next section to create a Skype account. Creating a Skype Account 1. -
Page 12: Adding Accounts
Chapter 2 Installing Skype 2. When the “Your Skype Personal Profile” window appears, enter the informa- tion in the appropriate text boxes. Click Update. The Skype account is created. Go to the next section to add contacts to the account. Adding Accounts 1. - Page 13 Actiontec Internet Phone Wizard User Manual 2. From the menu at the top of the window, select Tools, then Add a Contact…. 3. When the “Add a Contact” window appears, enter the name of another Skype user in the appropriate text box, then click Next.
- Page 14 Chapter 2 Installing Skype 4. A “Request Authorization” window appears. Make the appropriate selections, then click OK. 5. The contact is added. Click Finish. The contact has been added. To view the contact list, select the “Contact” tab from the main Skype window. To add assign a speed-dial number to an contact, go to the next section.
-
Page 15: Assign A Speed-Dial Number
Actiontec Internet Phone Wizard User Manual Assign a Speed-Dial Number 1. From the main Skype window, select the Contact tab, right-click on a contact name, and, in the menu that appears, select Assign Speed-Dial. 2. In the next window, enter a speed-dial number, then click OK. - Page 16 Chapter 2 Installing Skype 3. The speed-dial number is assigned to the contact. 4. Repeat to assign a speed-dial number to other contacts. After finishing with the installation configuration of Skype, go to the next chapter (“Connecting the Internet Phone Wizard Hardware”) to continue setting up the Internet Phone Wizard.
- Page 17 Actiontec Internet Phone Wizard User Manual This page left intentionally blank.
-
Page 18: Connecting The Internet Phone Wizard Hardware
Connecting the Internet Phone Wizard Hardware This chapter explains how to physically connect the Internet Phone Wizard to a computer, telephone, and phone line. There are two basic ways to connect the Internet Phone Wizard: Single Line or Dual Line. Single Line Connection When the Internet Phone Wizard is in Single Line mode, it can be used to make or receive Internet (computer-to-computer) phone calls using Skype only. - Page 19 Actiontec Internet Phone Wizard User Manual ☞ Note: If the Internet Phone Wizard needs to be disconnected from the computer for any reason, it must be reconnected to the same port. Connecting the Internet Phone Wizard to a different port may cause problems.
-
Page 20: Dual Line Connection
Chapter 3 Connecting the Internet Phone Wizard Hardware ☞ Note: If the Internet Phone Wizard needs to be disconnected from the computer for any reason, it must be reconnected to the same port. Connecting the Internet Phone Wizard to a different port may cause problems. - Page 21 Actiontec Internet Phone Wizard User Manual 7. Insert the other end of the supplied phone cable in a standard phone line out- let. The components should be connected similarly to the figure below: ☞ Note: If the Internet Phone Wizard needs to be disconnected from the computer for any reason, it must be reconnected to the same port.
- Page 22 Chapter 3 Connecting the Internet Phone Wizard Hardware 5. Insert the other end of the supplied phone cable in the microfilter. 6. Get the phone cable from the telephone and insert one end in the “Phone” port on the rear panel of the Internet Phone Wizard. 7.
- Page 23 Actiontec Internet Phone Wizard User Manual 5. Insert the other end of the supplied phone cable in the “Phone” port of the filter. 6. Get the phone cable from the telephone and insert one end in the “Phone” port on the rear panel of the Internet Phone Wizard.
-
Page 24: Installing The Internet Phone Wizard Software
Installing the Internet Phone Wizard Software After installing the Skype™ software (see chapter 2) and connecting the Internet Phone Wizard to a computer and phone outlet (see chapter 3), the Internet Phone Wizard software must be installed on the computer. ☞... - Page 25 Actiontec Internet Phone Wizard User Manual 3. In the next window, click Continue Anyway. The Internet Phone Wizard has been fully tested to work with Windows and 2000 and will not harm or hinder the performance of the computer. 4. When the next window appears, click Finish.
- Page 26 Chapter 4 Installing the Internet Phone Wizard Software 5. A “Congratulations” window appears. Click Next. 6. Another window appears. Enter an email address in order to be contacted about future online updates. Click Next. 7. A window with information about using Skype with the Internet Phone Wizard appears.
- Page 27 Actiontec Internet Phone Wizard User Manual 8. When Skype launches, a window appears. Click in the circle next to “Allow this program to use Skype,” then click OK. The Internet Phone Wizard software is installed, and Skype is running. To learn how to use the Internet Phone Wizard with Skype to place a regular or Internet call, see chapter 5, “Using the Internet Phone Wizard.”...
-
Page 28: Using The Internet Phone Wizard
Using the Internet Phone Wizard This chapter explains how to make a call using the Internet Phone Wizard, including calling an Internet telephone, calling traditional telephones, and answering a call. Before Making a Call Before making a call with the Internet Phone Wizard, make sure of the following: The computer meets or exceeds the minimum system requirements The computer is connected to the Internet A Skype™... -
Page 29: Calling An Internet Telephone
Actiontec Internet Phone Wizard User Manual Calling an Internet Telephone To make an Internet phone call using the Internet Phone Wizard: 1. Pick up the telephone receiver. A long dial tone (about 1 second) is heard, and the Internet Call light on the Internet Phone Wizard flashes. -
Page 30: Receiving A Call
Chapter 5 Using the Internet Phone Wizard Receiving a Call 1. The telephone connected to the Internet Phone Wizard rings. 2. The Internet Phone Wizard’s Regular Call or Internet Call light flashes, depending on what kind of incoming call is being received. 3. -
Page 31: Quick Reference Table
Actiontec Internet Phone Wizard User Manual Quick Reference Table... -
Page 32: Troubleshooting
Troubleshooting If you have any troubleshooting issues or wish to see a frequently asked questions list, go to www.internetphonewizard.com/support... - Page 33 Actiontec Internet Phone Wizard User Manual This page left intentionally blank.
-
Page 34: Specifications
Specifications Model Number 101 (Internet Phone Wizard) PC Interface port Telephone Interface -11 ports (Phone, Line) LED indicators Regular Call, Internet Call, Ready Audio Support Microsoft , and Mixer Dimensions (LxWxH) 11.5 x 8.5 x 2.5 cm (4.5 x 3.3 x 1 in.) Weight 125 g (4.4 oz.) Operating temperature... - Page 35 Actiontec Internet Phone Wizard User Manual Relative Humidity > 80 % (non-condensing) Warranty 1 year ☞ Note: Specifications are subject to change without notice.
-
Page 36: Notices
Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Actiontec Electronics, Inc., may void the user’s authority to operate the equipment. Declaration of conformity for products marked with the FCC logo – United States... -
Page 37: Miscellaneous Legal Notices
© Actiontec Electronics, Inc. Actiontec Installation Buddy, Connection 2005 Solutions for the Digital Life, Actiontec Digital Gear, and the Actiontec logo are trademarks or registered trademarks of Actiontec Electronics, Inc. All other names are the property of their respective owners. -
Page 38: Limited Warranty
Software: Actiontec Electronics warrants to Customer that each software program licensed from it will perform in substantial conformance to its program specifica- tions, for a period of ninety (90) days from the date of purchase from Actiontec Electronics or its authorized reseller. Actiontec Electronics warrants the media con- taining software against failure during the warranty period. - Page 39 The repaired or replaced item will be shipped to Customer, at Actiontec Electronics’ expense, not later than thirty (30) days after Actiontec Electronics receives the defective product.
- Page 40 This warranty gives you specific legal rights which may vary depending on local law. Dispute Resolution: The customer may contact the Director of Technical Support in the event the Customer is not satisfied with Actiontec Electronics’ response to the complaint. In the event that the Customer is still not satisfied with the response of the Director of Technical Support, the Customer is instructed to contact the Director of Marketing.
- Page 41 Actiontec Internet Phone Wizard User Manual Governing Law: This Limited Warranty shall be governed by the laws of the State of California, U.S.A., excluding its conflicts of laws and principles, and excluding the United Nations Convention on Contracts for the International Sale of Goods.
