To Extend the Jack(s):
• To extend the jack(s), follow all the above steps EXCEPT DO NOT Manually shift directional
valve DV-1.
• Following manual override operation, failure to return all valves to normal/original position
may result in one or more jacks drifting/traveling down from their retracted (stowed) position.
For cartridge valves, rotate the center 1/8" Allen screws fully counter-clockwise. For valve
DV-1 rotate the red knob so that it will snap into the in position.
Manual Override for Bi-Rotational
Pump #'s 2532, 2542, 3195, 3195KS & 2542KS
Your hydraulic pump is equipped with a bi-rotational motor.
• You will use a 2000 r.p.m. drill and a 7/16" socket or 1/4" Allen Driver.
• Care must be taken to ensure neither the drill nor the socket contact any wires or hydraulic hoses
while in use.
To Operate Your Jack(s) Using the Manual Override
(with Bi-Rotational Motor)
• The individual cartridge valves are clustered together on the side of the pump manifold. They are
labeled 1 thru 4. Locate the screws on the appropriate cartridge valve(s). Using a 1/8" Allen wrench,
turn the screw(s) clockwise until seated in.
• The pump may or may not have a DV-2 valve on the opposite side of the manifold. If it does turn
the 1/8" Allen screw clockwise until seated in.
There are 2 motor types.
• Some motors have a black plastic plug in the end of the motor. Remove this plug by prying with a
small screwdriver.
• Some motors have a foil sticker on the end, remove this sticker.
• Place the drill with the 7/16" socket or 1/4" Allen on the manual override shaft located at the end of
the motor.
• To retract your jack(s) run the drill in the counter-clockwise direction. To extend your jack(s), run
the drill in the clockwise direction.
See drawings on next page.
Following manual override operation, failure to return all valves to normal position may result in one or
more jacks drifting/traveling down from their retracted (stowed) position. For cartridge valves, rotate
the center screw fully counter-clockwise.
