During typical operation, the LED's on the bottom left hand corner of the keypad should NOT be
illuminated. The only LED that should light is the OPERATING LED, which should flash during
operation.
Power LED
Jack LED
Operating LED
Low Volatage LED
Engage Park Brake LED
Ignition On LED
Excess Slope LED
If the LOW VOLTAGE, or EXCESS SLOPE LED's illuminate, you have an error condition that must be
corrected prior to operating the jacks.
Note: After an Auto Level process the operation light should turn off and the Excess Slope light should
be off. This indicates that the system has finished leveling and is within the .5-degree (approx. 7/16 inch
If the Excess Slope light is on, then the system was not able to complete the process within the
.5-degree specification. There are several possibilities to include but not limited to Low Voltage, jack(s)
Panel Indicator LED's
ON Red when Power is ON
OFF when power is OFF
SLEEP MODE Flashes every 1 second
ON Red when Jack(s) are deployed
OFF when Jack(s) are stowed
ON Red w/Auto Level or All Retract
OFF when keypad is idle or sleeping
ON Red when voltage is below 10.5 VDC
OFF when voltage is above 10.5 VDC
ON Red when park brake is not set
OFF when park brake is set
ON Red when ignition is in the ON position
OFF when iginition is off
ON Red following an Auto Level attempt if
system cannot overcome slope
OFF when slope is not excessive
over 4 feet) front to rear and side to side leveling specification.
running out of travel or system/component failure.
