ElMod ThinkTank Blaster 2 Detailed Instructions For Assembly And Operation page 2

Operation state LEDs
-_______
--------
-----_-_
---_-_-_
Power-LED
_____-_-
___-_-_-
_-_-_-_-
Busy-LED
Switching the motor on and off
After the installation of the ThinkTank blaster, the engine is switched off after power up by default.
You can change the state of the engine as follows:
• HL-Tanks without S&S or tanks with installed ThinkTank proportional set: move the left lever to
the left upper position.
• HL-Tanks with S&S: After power up push the ignition button on the radio and wait approx. 10
seconds (the time span which is required for the original HL-ignition sequence to be finished).
Move the left lever to the left upper position.
• Tanks with installed ThinkTank C6 proportional set: move the control element of channel 6 to
the most upper position.
This procedure switches the tank alternately on and off. You cannot move the tank when the
engine is off.
User defined samples
With a six-channel proportional set up to four sounds can be defined by the
user. Every set of samples is already equipped with demo samples. To play
them cable D hast to be connected with connection 4 and the proportional
receiver.
cable black/brown: channel 5 (channel 7 with ThinkTank C6 Prop Set)
cable red: channel 6 (channel 8 with ThinkTank C6 Prop Set)
The plugs are not polarity proof! Make sure that the black cable is connected to the ground (-) and
the colored wires are connected to the signal pins (S) of the receiver.
The samples are activated by full deflection of the controls of the channels 5 and 6 and can be
terminated by moving the controls in the opposite direction.
Optional sample sets
Take a look at our website for information about new sets of samples. New sets can be
downloaded for free and transfered to the SD-card via USB-card reader.
Please visit our website and take a look on the FAQ for in-depth information
Booster is looking for connected modules
Booster is operational
(on)
no SD card found or card is defect
initialisation file not found or damaged file
system on the SD card
warning: maximum number of samples for
one set exceeded
warning: a defined sample could not be
found in the set of samples
another critical error
flickers when playing the samples
Nicht geeignet für Kinder unter 14 Jahren.
Not suitable for Children under 14 years.
Ne convient pas pour des enfants de moins de 14 ans.
Niet geschikt voor kinderen onder de 14 jaar.
