Summary of Contents for Joerns Oxford Adaptive Power Cradle
-
Page 2: Table Of Contents
Oxford ® English Adaptive Power Cradle Contents 1. Installing your Oxford 4-point Adaptive Power Cradle .......... 2. Component Parts....................3. Assembly Instructions (connection and removal) ..........4. Sling Attachment ....................5. Safety Precautions ....................6. Cradle Operation ....................7. Service & Maintenance ..................11 8. -
Page 3: Installing Your Oxford 4-Point Adaptive Power Cradle
Oxford ® English Adaptive Power Cradle 1. Oxford 4-point Adaptive Power Cradle The Oxford Presence lift is fitted with a 6-point spreader bar as standard and the Stature lift is fitted with a 4-point cradle as standard (see fig. 1). Standard configuration Standard configuration 6-point spreader bar... -
Page 4: Component Parts
Oxford ® English Adaptive Power Cradle 2. Component Parts: Adaptive Power Cradle The following components are included with your 4-point Adaptive Power Cradle (see fig. 4). 1 x 4-point Adaptive Power Cradle 1 x Battery charger 2 x Rechargeable batteries, NiMH 2 x Black plastic caps for Stature and Presence boom 1 x User/service manual (not shown) Black Plastic Caps... - Page 5 Oxford ® English Adaptive Power Cradle CAUTION: Prior to removing the quick release pin, the cradle needs to be supported by a stationary object such as a workbench or table. This will prevent the cradle from dropping suddenly which could result in an injury or damage to the cradle. Connection: To connect, raise the 4-point Adaptive Power Cradle up towards the boom slot.
-
Page 6: Sling Attachment
Oxford ® English Adaptive Power Cradle 4. Sling Attachment Attachment of the Comfort sling to your Adaptive Power Cradle: The Comfort sling attaches to the cradle studs via the Securi3 safety clip system (shown below); each sling is supplied with instructions. Please study the instruction guide before use (See fig. 8). Fig. - Page 7 Oxford ® English Adaptive Power Cradle • When placing the cradle and sling in the most upright position do not leave the patient unattended. The patient could slump forward in the sling, which could result in an injury to the patient. •...
-
Page 8: Cradle Operation
Oxford ® English Adaptive Power Cradle 6. Cradle Operation Hand Control: Operating the 4-point Adaptive Power Cradle is a very easy process. Once the patient has been placed in the sling and the sling has been attached to the Adaptive Power Cradle, the cradle is positioned by using the hand control located in the cradle handle (see fig. - Page 9 If it is more convenient to do so, place on charge every night. The charger WILL NOT allow the battery to overcharge. • Battery or charger is not to be opened by unauthorized personnel. (Contact Joerns Healthcare or your distributor for warranty and repairs). •...
- Page 10 Oxford ® English Adaptive Power Cradle • Never run the battery completely flat. As soon as the audible warning sounds, complete the lifting operation in hand and place on charge. • CAUTION: Never store the battery for long periods without regular charging throughout the storage period.
-
Page 11: Service & Maintenance
Oxford ® English Adaptive Power Cradle 7. Service and Maintenance Schedule 1. Check for freedom of rotation (power cradle) ü ü ü 2. Check for wear on the central pivot point (the pivot pin located in the ü ü cradle frame) 3. - Page 12 Oxford ® English Adaptive Power Cradle Service Parts: Fig. 14...
- Page 13 Oxford ® English Adaptive Power Cradle Part No. Description 0Y0457 Actuator 0Y0459 Battery charger with UK lead 0Y0460 Battery charger with EU lead 0Y0458 Battery charger with US lead 0Y0461 Control box 0Y0462 Battery 0Y0463 Hand switch assembly 0Y0464 Wire harness between conrol box, actuator and switch 0Y0465 Hardware (fixings) 0Y0380...
-
Page 14: Electrical Specification
Oxford ® English Adaptive Power Cradle 8. Electrical Specification Batteries ..............24VDC, rechargeable NiMH sealed Battery capacity……………………......1400mAh Charger rated Input………………….......100 - 240V AC// 24 VDC 50/60 Hz Max. 75mA Charger rated Output………………......Max 28,4VDC Electric Shock Protection Charger……………………………….......Class II Degree of shock protection Charger……………………………….... -
Page 15: Warranty
(UK customers only). If you are in doubt where your lift was purchased, Joerns Healthcare can trace the supplier if you provide the serial number of the cradle, which is situated under the handle that houses the control switches.
