Related Manuals for Joerns Oxford 0Y0050
Summary of Contents for Joerns Oxford 0Y0050
- Page 1 User Instruction Manual Oxford 4-Point Positioning Cradle ® To avoid injury, read user manual prior to use.
- Page 2 Oxford ® English 4-Point Positioning Cradle Contents Safety Warnings..................3 Assembly Instructions ................4 Warranty ....................5...
- Page 3 Oxford ® English 4-Point Positioning Cradle 1. Safety Warnings NOTE: Assembly instructions pertain to the type of lifter boom that you will be attaching to the cradle. Follow the appropriate instructions based upon your lifter and model ordered. WARNING • The Oxford Cradle does not increase the maximum weight capacity of a lifter.
- Page 4 Oxford ® English 4-Point Positioning Cradle 2. Assembly Instructions Lifter Model: OXF-PRESENCE OXF-STATURE Cradle Model Number: 0Y0050 0Y0189 Tools Required: Flat blade screwdriver FOLLOW THESE INSTRUCTIONS EXACTLY: Your Oxford Presence lift has the option of using both a 6-point spreader bar or 4-point positioning cradle.
- Page 5 Oxford ® English 4-Point Positioning Cradle 2. Pull the pin out (Fig. 3, item 1). 3. Support the spreader bar, and then pull the pin sleeve (Fig. 3, item 2) in the opposite direction, removing it from the boom. This will release the spreader bar completely (Fig 4). Fig.
- Page 6 Oxford ® English 4-Point Positioning Cradle 3. YOU MUST CHECK THAT THE PIN IS SECURELY FITTED. To do this, press your finger into the barbed end. If the pin remains stationary, the lift is safe to use (Fig. 7). Conduct final inspection to ensure that all parts are secure (Fig. 8). Fig.
- Page 7 If you are in doubt as to where your product was purchased, Joerns Healthcare can trace the supplier if you quote the serial number of the lift. Contact details can be found on the rear cover of this manual.
