Acnodes KDW 5170 Specifications

» Specifications
Material
Heavy-duty steel
Keyboard and touch pad
105-keys keyboard,
Multi-language: US, RU, GR, FR, UK, IT, KR, CH
2 buttons touch pad.
LCD Panel
Size: 17", 16:9 wide screen
Brightness (cd/m^): 450nit
Contrast ratio: 600:1
Resolution:1280 x 768
Refersh rate: 80Hz
colors 16.7M (8bits color)
Viewing Angle:(80/80)Horizontal, (80/80) Vertical
Backlight Unit:
2 replaceable CCFLs, LTCFL: 35,000 hours
Anti-glare tempered glass to protect LCD panel
Optional for resistive-type touch screen (RS-232 port)
Connectors
1 x D-Sub 15 pin (female) for VGA
2 x PS/2 ports for Keyboard and touch pad
Cable:
1 x 6' 3-in-1 (VGA /keyboard / touch-pad) KVM cable
1 x 6' audio cable
Stereo speaker:
2 x 5W stero speaker
Drawer Design
Front panel with 2 x Thumb screw for the security
Slide rail with self-locking device
Rear bracket extension up to 32" depth
LCD panel folding angle up to 110°
20957 Currier Road Suite #D
Walnut, CA 91789
tel: 909.598.7388, fax: 909.598.0218
KDW 5170
17" 1280 x 768 LCD monitor
16:9 wide screen
105-key keyboard, touch pad
» Features
» 1U compact design, 20" depth
» 17" 1280 x 768 wide LCD display
» OSD (On Screen Display) function
» PS/2 105-key keyboard with touch pad
» Anti-glare tempered glasses to protect LCD display
» 110/220VAC 50W power supply
Power supply
Industrial level Auto-switching 50W power supply
for 90V~264V AC input
Color
Black
Operation Temperature
0°C to 50°C (32°F to 122° F)
Weight
32lb
Dimension
17.42"(W) x 20"(D) x 1.74"(H)
Safty:
FCC, CE
» Ordering Guide
KDW 5170:
1U 17" 1280 x768 16:9 wide screen rackmount monitor
keyboard drawer
» Options
