Acnodes KD 9171N Specifications

» Specifications
Material
Heavy-duty steel
LCD Panel
Size: 17"
Max. Resolution: 1280x1024
Brightness 250 cd/m2
Contrast Ratio 400:1
Frequency Horizontal: 31.5 to 80KHz.
Vertical: 56 to 75Hz.
Response Time 25 ms typical
Viewing Angle:
Horizontal: -80/ +80 degrees
Vertical: -80 / +80 degrees
Input Signal Video: Analog RGB
Sync: H/V Separate (TTL Brightness (cd/m^): 250nit)
Colors 16M colors
Video Connector Signal: 15-pin mini D-sub, detachable
Plug & Play: DDC1 and DDC2B
On-Screen-Controls
Brightness, Contrast, Position (Vertical & Horizontal)
Auto Adjust, OSD Horizontal & Vertical, position, Load and Save
values.
Keyboard
Compatibility: IBM AT, PS/2, DOSV
Key layout: 88 keys
Switch life: 5 million life cycles
» Ordering Guide
KD 9171N:
17" 1280 x 1024 1U rackmount monitor drawer, keyboard, Optical
mouse
20957 Currier Road Suite #D
Walnut, CA 91789
tel: 909.598.7388, fax: 909.598.0218
KD 9171N
17" 1280 x 1024 LCD monitor
Built-in keyboard / Touch pad
1U rackmount drawer
» Features
» 1U rackmount compact design, only 25" depth
» Rack slide rail up to 36" rack cabinet
» 17" 1280x1024 TFT LCD display
» OSD (On Screen Display) function
» PS/2 type 88 key keyboard with optical mouse
» 110/220VAC 50W power supply
Mouse
Microsoft IntelliMouse optical PS/2 or USB mouse
Connectors
1 x D-Sub 15 pin (female) for VGA
1 x P/S 2 for Keyboard
1 x P/S 2 or USB for optical mouse
Drawer Design
High load-rating slide rail with angle bracket extension up to 35"
depth
Power Adapter
Industrial level Auto-switching 60W power supply for 85V~264V
AC input
Color
Black
Environmental
Environment Temperature Operating: 0 to 50 degrees C
Storage: -20 to 60 degrees C
Humidity Operating: 10% to 85% non-condensing
Gross Weight
23lb
Dimension
19"(W) x 25"(D) x 1.75"(H)
» Options
