TROUBLESHOOTING GUIDE

WARNING: To reduce the risk of shock and unintended operation, turn off
power and remove power pack before servicing .
Vacuum is not picking up debris, no suction or light suction .
(Refer to Maintenance section for more information .)
• Check filters to see if they need cleaning. Follow instructions for rinsing and completely
air-drying the filters before reinserting in the vacuum.
• Dust cup may be full; empty dust cup.
• Check floor nozzle for blockages; clear blockages if required.
• Remove any string, carpet fibres, or hair that may be wrapped around the brushroll and Soft Roller
or trapped behind the Soft Roller.
• Check connection between handvac and wand for blockages; clear blockages if required. If the
issue persists, please contact Customer Service.
Vacuum lifts rugs .
• Check that vacuum is in EXTENDED RUNTIME mode. Take care when vacuuming rugs with
delicately sewn edges.
• Turn off the unit to disengage the brushroll and restart with the Power button.
Brushroll/Soft Roller does not spin .
• If Brushroll Indicator Light on the floor nozzle turns red, the brushroll and/or Soft Roller have
stopped spinning. Immediately turn off and remove Lithium ION Power Pack from handheld vacuum
and remove blockage before reconnecting and turning vacuum back on. If light turns green, the
blockage has been successfully cleared. If it remains red, please contact Customer Service.
• If headlights are not illuminated, there is a connection issue between the handheld vacuum, wand,
and nozzle. Try disconnecting and reattaching the pieces. If the headlights still do not illuminate,
please contact Customer Service.
Vacuum turns off on its own .
There are several possible reasons for the vacuum turning off on its own, including blockages, Lithium
ION Power Pack issues, and overheating. If vacuum turns off on its own, perform the following steps:
1. Check LED lights on Lithium ION Power Pack to see if it needs to be recharged. If power pack
does not need charging, turn off vacuum and remove power pack.
2. Empty dust cup and clean filters (see Maintenance section).
3. Check wand, accessories, and inlet openings and remove any blockages.
4. Allow unit and Lithium ION Power Pack to cool for at least 45 minutes, until it returns to room
temperature.
5. Return power pack to vacuum and press Power button.
Note: If vacuum still does not operate properly, contact Customer Service.
LED lights on ION Power Pack are flashing .
• If top 2 or bottom 2 LED lights are flashing (Fig. A, Fig. B), call Customer Service.
• Bottom LED light is flashing (Fig. C): Lithium ION Power Pack needs to be charged.
• Top and bottom LED lights are flashing (Fig. D): Lithium ION Power Pack temperature is not optimal,
so charging is temporarily paused. Leave power pack plugged in and charging will resume soon.
Fig. A Fig. B
63 63
Fig. C Fig. D
LIGHT INDICATOR
Unit temperature is high.
Turn off vacuum. While unit
"FLOOR" and "CARPET"
is cooling, look for blockages
LEDs alternate
and remove any that are found.
illuminating
Filters may also need to be
cleaned.
"EXTENDED" and "MAX
Blockage detected. Turn off
POWER" LEDS are
unit and remove blockage.
flashing together
Brushroll garage is not properly
closed. Close the door by
inserting the tabs on the
Headlights are flashing
lid into the slots in the floor
nozzle, then pressing down on
the lid, above the headlights,
until both sides click into place.
WHAT IT MEANS
