Helmholz 700-850-4PS01 Quick Start Manual
Profinet switch 4-/8-/16-port
Hide thumbs
Also See for 700-850-4PS01:
- Quick start manual (20 pages) ,
- Quick start manual (20 pages) ,
- Manual (43 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Helmholz 700-850-4PS01
Summary of Contents for Helmholz 700-850-4PS01
- Page 1 Quick Start Guide Version PROFINET switch 4-/8-/16-port Order number: 700-850-4PS01, 700-850-8PS01, 700-850-16PS01 Helmholz GmbH & Co. KG | Hannberger Weg 2 | 91091 Großenseebach | Germany 22.06.2020 Phone +49 9135 7380-0 | Fax +49 9135 7380-110 | info@helmholz.de | www.helmholz.de...
-
Page 2: Table Of Contents
Content Safety instructions ....................2 Introduction ......................3 Preparing the PROFINET switch ................3 Connecting ..........................3 Setup and use ....................... 4 Install GSDML file ......................... 4 Setup in the hardware-configuration .................... 5 Setting the port properties......................6 Assign the PROFINET switch a name ..................... 7 Further configuration and diagnosis via the web interface ............ -
Page 3: Introduction
Please consider the safety instructions for the product, which can be found in the PN/CAN-Gateway manual. You can download the manual from the website www.helmholz.de in the download area of the product or use the shown QR code. This document is intended to explain the initial commissioning of the PROFINET switch in a standard application case. -
Page 4: Setup And Use
4 Setup and use 4.1 Install GSDML file You can download the GSDML file from the website www.helmholz.de in the download area of the product or use the shown QR code. PROFINET switch 4-port PROFINET switch 8-port PROFINET switch 16-port You can find in the “Manage general station description files”... -
Page 5: Setup In The Hardware-Configuration
Following installation, the PROFINET switch can be found in the hardware catalog under “Other field devices -> PROFINET IO -> Network Components -> Helmholz GmbH & Co. KG -> Helmholz PN-Switch”. Add the “PROFINET-Switch, 4-port”, “PROFINET-Switch, 8-port” or “PROFINET-Switch, 16-port” device to the project and connect it with your PROFINET network. -
Page 6: Setting The Port Properties
4.3 Setting the port properties Each port of the PROFINET switch can be individually configured. “Activate this port” The port can be switched off here. This option is recommended when the port should not be used. Unauthorized trespass into the network is prevented. -
Page 7: Assign The Profinet Switch A Name
If configuration has taken place correctly, the PROFINET “BF” LED is off. The Helmholz IPSet tool, which can be downloaded at no charge from the Helmholz website, can also be used to set the PROFINET name. Scan the following QR code to download the IPSet tool:... -
Page 8: Further Configuration And Diagnosis Via The Web Interface
4.5 Further configuration and diagnosis via the web interface Via the web interface, the status of the PROFINET switch can be queried and further functions can be configured. Furthermore, a firmware update can be performed via the web interface. The web interface can be operated as soon as the device has a network configuration. -
Page 9: Technical Data
6 Technical data Order no. 700-850-4PS01 700-850-8PS01 700-850-16P01 PROFINET switch 4-port, PROFINET switch 8-port, PROFINET switch 16-port, Name managed managed managed PROFINET switch 4-port, PROFINET switch 8-port, PROFINET switch 16-port, Scope of delivery with power supply plug with power supply plug... - Page 10 They are also provided in our download area of the respective products under www.helmholz.de. We also offer to send you or any third party the complete corresponding source text of the respective open source software for an at-cost fee of 10.00 Euro as a DVD upon request. This offer is valid for a period of three years, starting from the date of product delivery.
