Icom IC-F3061T Adjustment page 8

Adjustment No.
For verify of RX adjustment must be done with
NOTICE FOR RX
a SG set as;
ADJUSTMENTS
Freq.=1kHz
Dev.=70%
Connect an 8 ohms load to the SP terminal.
RX SENSITIVITY
ADJUSTMENT Set the SG as;
Adjust the "BPF C ALL" on the ADJ screen for
maximum sensitivity.
Verify the sensitivity as below.
RX SENSITIVITY
Sensitivity
VERIFY
"RX SENSITIVITY" must be adjusted before
S-METER
"S-METER"."S-METER" must be adjusted
ADJUSTMENT
if "RX SENSITIVITY" is adjusted again.
Setting S3 level
Set the SG as;
Setting S1 level
Set the SG as;
Adjustment for IC-F3061T/S,IC-F3161T/S,IC-F3161DT/DS
Adjustment Condition & Tuning
FREQUENCY
LEVEL
Less than
Freq.
Level
Freq.
Level
around 136MHz
+20dBu
-10 dBu (@12dB SINAD)
around 136MHz
+23dBu
around 136MHz
-7dBu
Value REF No.
(ADJ screen)
BPF C ALL
(ADJ screen)
RSSI
RSSI S3 Level
(ADJ screen)
RSSI
RSSI S1 Level
CK.POINT
RSSI line
ANT connector
EXT. SP
ANT connector
ANT connector
PAGE5
