Reinstall the metal bracket frame to the housing.

Connect the power and disk drive cables to the hard disk.

Replace the computer cover.

Installing an expansion card

To install an expansion card:

Note: The mainboard model shown in the figures below may not

be exactly the same with the one found in your computer.

Remove the computer cover.

Locate an empty PCI slot on the mainboard.

Remove the screw that holds the bracket to the computer. Save

the screw.
