To reconfigure your computer

Your computer automatically detects the amount of additional

memory installed. Run the BIOS Setup utility to view the new value for

total system memory and make a note of it. For more information on

BIOS, refer to the Veriton 5200 series Online guide (see "Accessing your

online guide" on page 5).

Follow these steps to replace your computer's hard disk:

Note: The mainboard model shown in the figures below may not

be exactly the same with the one found in your computer.

Remove the computer cover.

Detach the power and disk drive cables from the hard disk.

Remove the screw that secures the metal bracket frame to the

housing.

Lift up the metal bracket and pull it out.
