4 Gently pull the DIMM upward to remove it from the socket (b).

To install a DIMM

1 Locate the DIMM socket on the mainboard.
2 Open the clips on the socket.
3 Align then insert the DIMM into the socket (a).
4 Press the clips inward to lock the DIMM into the socket (b).
Note: The DIMM sockets are slotted to ensure proper installation.
If you insert a DIMM but it does not fit easily into the socket, you
may have inserted it incorrectly. Turn the DIMM and try to insert it
again.
