Installation & Operation Manual
2.2 Package Contents
Before starting, check that you have the correct parts as indicated below. If any parts
are missing or incorrect, please call your local distributor or technical support at
1-800-822-7933 for assistance.
Item Description
1
AquaLink
RS System Level
®
2
Transformer
3
Transformer Bracket
4
PIB Bracket
5
System Level Board Hinge
6
iQ20 Web Connect Device
7
Low Voltage Dead Front
8*
Enclosure Conversion Wiring Diagram Label
9*
Professional Installation Required Label
*NOT SHOWN - The AquaLink RS Conversion Kit for Pentair
includes a wiring diagram overlay, button function/UI label and a sheet of user
interface auxiliary labels.
Table 1.
Kit Contents
1
4
7
Figure 1.
Kit Contents
5
KIT
QTY
1
1
1
1
1
1
1
1
1
®
enclosures
2
3
6
Page 9
Need help?
Do you have a question about the AquaLink RS Conversion Kit and is the answer not in the manual?
