For pentair enclosures

Advertisement

Quick Links

FOR YOUR SAFETY - This product must be installed and serviced
by a contractor who is licensed and qualified in pool equipment by the
jurisdiction in which the product will be installed where such state or
local requirements exist, the maintainer must be a professional with
sufficient experience in pool equipment installation and maintenance
so that all of the instructions in this manual can be followed exactly.
Before installing this product, read and follow all warning notices and
instructions that accompany this product. Failure to follow warning
notices and instructions may result in property damage, personal
injury, or death. Improper installation and/or operation may void the
warranty. Improper installation and/or operation can create unwanted
electrical hazard which can cause serious injury, property damage, or
WARNING
death. Turn off all circuit breakers required in order to
prevent the possibility of electric shock
ATTENTION INSTALLER: This manual contains
important information about the installation, operation
and safe use of this product. This information should
be given to the owner/operator of this equipment.
AquaLink
RS Conversion Kit
®
for Pentair
Installation Instructions
Enclosures
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AquaLink RS Conversion Kit and is the answer not in the manual?

Questions and answers

Summary of Contents for Jandy AquaLink RS Conversion Kit

  • Page 1 AquaLink RS Conversion Kit ® for Pentair Enclosures ® Installation Instructions WARNING FOR YOUR SAFETY - This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed where such state or local requirements exist, the maintainer must be a professional with sufficient experience in pool equipment installation and maintenance so that all of the instructions in this manual can be followed exactly.
  • Page 2: Table Of Contents

    Page 2 Jandy AquaLink RS Conversion Kit ® ® Table of Contents Section 1. Important Safety Instructions ..3 Section 2. Package Contents ......4 Pool Pump Suction Entrapment Prevention Guidelines ......7 Package Contents ........9 Section 3. Product Compatibility....10 Section 4.
  • Page 3: Section 1. Important Safety Instructions

    Page 3 Installation & Operation Manual Section 1. Important Safety Instructions READ AND FOLLOW ALL INSTRUCTIONS All electrical work must be performed by a licensed electrician and conform to all national, state, and local codes. When installing and using this electrical equipment, basic safety precautions should always be followed, including the following: protection installed upstream of the WARNING...
  • Page 4: Section 2. Package Contents

    8 AWG (8.4 mm2) copper wire to warrant or guarantee that the chlorinated any metal ladders, water pipes, or other water generated by the Jandy ® metal within five (5) feet (1.52 m) of the Series chlorine generating device will not pool/spa.
  • Page 5 Page 5 Installation & Operation Manual • Unconsciousness resulting in a • All metal components used in and danger of drowning around a pool should be of a high To Reduce the Risk of Injury: grade, quality stainless steel. • The water in a spa should never •...
  • Page 6 Page 6 Jandy AquaLink RS Conversion Kit ® ® • Do not use drugs or alcohol before • Operating a chlorine generator or during the use of a spa or hot without water flowing through tub to avoid unconsciousness and the cell may cause a build up of possible drowning.
  • Page 7: Pool Pump Suction Entrapment Prevention Guidelines

    Page 7 Installation & Operation Manual However, there is no guarantee • Consult the dealer or an that interference will not occur experienced radio/TV technician in a particular installation. If this for help. equipment does cause harmful interference to radio or television Modifications made to this equipment, reception, which can be determined which are not authorized by the...
  • Page 8 Main Drain Sump Main Drain Sump Tee and Main Drains Suction Outlet Suction Outlet (Main Drain) (Main Drain) Valves permitted only after tee Pump SAVE THESE INSTRUCTIONS Aqualink RS Conversion Kit is ETL Classified to the following standards UL 1563 CSA C22.2#218.1...
  • Page 9: Package Contents

    Web Connect Device Low Voltage Dead Front Enclosure Conversion Wiring Diagram Label Professional Installation Required Label *NOT SHOWN - The AquaLink RS Conversion Kit for Pentair ® enclosures includes a wiring diagram overlay, button function/UI label and a sheet of user interface auxiliary labels.
  • Page 10: Section 3. Product Compatibility

    This conversion kit can be used on most versions of the following Pentair systems. Before beginning contact Fluidra technical support for validation on the specific system configuration and/or systems not referenced. AquaLink RS Conversion Kit for use with the following equipment ® EasyTouch ®...
  • Page 11: Section 4. Remove The Pentair Control Panel

    ® Before beginning the installation, verify the location has adequate WiFi coverage or a wired Ethernet connection to the home router. The AquaLink RS Conversion Kit uses a connection to the Internet. If Internet access is questionable or not functional, it is advised to not proceed with the Pentair control panel removal and changes until a access is ensured.
  • Page 12 Page 12 Jandy AquaLink RS Conversion Kit ® ® 5. Remove the top two screws on Pentair control panel, swing panel down to allow access to wiring behind it, see Figure 3(a). Figure 3. Remove Pentair Control Panel Screws 6. Disconnect power connection from the transformer.
  • Page 13 Page 13 Installation & Operation Manual 14. Remove 2 outer retaining screws from transformer assembly, see Figure 5(b). Figure 5. Remove Transformer Assembly 15. Remove old transformer from enclosure. 16. Remove 2 outer retaining screws on top of the High Voltage cover panel, see Figure 6(a).
  • Page 14: Transformer Located On High Voltage Side

    Page 14 Jandy AquaLink RS Conversion Kit ® ® 22. Remove or bend back circuit breaker mounting tab. 4.2 Transformer located on high voltage side 1. Turn off power at the breaker panel. 2. Remove 2 retaining screws on top of the High Voltage cover panel, see Figure 7(a).
  • Page 15 Page 15 Installation & Operation Manual 8. Remove the top two screws on Pentair control panel, swing panel down to allow access to wiring behind it, see Figure 9(a). Figure 9. Remove Pentair Control Panel Screws ® 9. Disconnect power connection from the transformer. 10.
  • Page 16: Section 5. Install The Aqualink Rs Conversion Kit

    Page 16 Jandy AquaLink RS Conversion Kit ® ® 15. Disconnect all temperature sensors. 16. Remove the 3 retaining screws from circuit breaker assembly located behind control panel, see Figure 11(a). Figure 11. Remove Circuit Breaker Assembly Section 5. Install the AquaLink ®...
  • Page 17: New Transformer Installation

    Installation & Operation Manual 5.2 New Transformer Installation CAUTION: The Jandy Aqualink transformer must be wired to 120V. 1. Use new transformer bracket to install new transformer in the control panel compartment, see Figure 13(a). Ensure all screw holes and openings not being used are properly closed off and sealed.
  • Page 18: Install Conversion Kit

    RS Conversion Kit hinge using the 2 retaining screws ® removed in section 2.4, see Figure 14(a) 2. Slide 3 tabs on AquaLink RS Conversion Kit PIB into the slots in bracket, see Figure 14(b). 3. Secure AquaLink RS Conversion Kit PIB onto bracket with 2 top screws.
  • Page 19: Connect Sensor Wires

    Page 19 Installation & Operation Manual 5.4 Connect Sensor Wires Connect the following sensors: • Water Temperature • Air Temperature • Solar Temperature (optional) 1. Reconnect the water, air, and optional solar sensors to the green terminal bar on the RS board, see Figure 15. Figure 15.
  • Page 20: Connecting Auxilliary Equipment To Pcb

    NOTE Pool filter pump socket is on the far left of the PCB and the spa filter pump relay socket is on the right after AUX 6 socket. 5.7 Finalize Hardware Installation 1. Install retaining screw on top left of AquaLink RS Conversion Kit chassis, see Figure 16(a). Figure 16 AquaLink RS Conversion Kit Mounting...
  • Page 21: Test The Equipment

    Page 21 Installation & Operation Manual 2. Secure AquaLink RS Conversion Kit cover with 2 screws, see Figure 17(a). 3. Align tabs on bottom of low voltage dead front to the slots in the power center enclosure. 4. Secure the cover panel to the power center using the screws removed in section 2.4, see Figure 17(b).
  • Page 22 Turn this switch ON if you want to control both speeds of a two-speed spa pump. With this switch on, the spa pump button on the AquaLink RS Control Panel will control high speed and the AUX 2 button will control low speed. IMPORTANT You must also install a Jandy Two- Speed Relay. ®...
  • Page 23: Dip Switch Settings

    This switch is used for configuring solar priority or heat pump priority. Set this switch to ON if Heat Pump Priority will be used. Set this switch to OFF if Solar Priority is to be used. AquaLink RS Conversion Kit available accessories All Button Indoor Controller OneTouch Indoor Controller...
  • Page 24: Dip Switch Settings For Solar/Heat Pump

    Page 24 Jandy AquaLink RS Conversion Kit ® ® S1 DIP Switch # No solar system installed. Changes air sensor to solar Air temperature is sensor. Air temperature displayed. no longer displayed. Adjustable Freeze Kit must be added for freeze protection.
  • Page 25: Section 7. Install And Program The Iq20

    Page 25 Installation & Operation Manual GREEN 10-PIN RS485 HEAT DESCRIPTION S2-1 TERMINAL PUMP Sensor Connected In this configuration there installed is Solar Heating and there is Solar Priority. There is Heat Pump. There is Heat Pump Priority. No sensor Not connected In this configuration there installed...
  • Page 26 Page 26 Jandy AquaLink RS Conversion Kit ® ® NOTES...
  • Page 27 Page 27 Installation & Operation Manual NOTES...
  • Page 28 Zodiac Pool Systems LLC UL STD 1563 2882 Whiptail Loop # 100, Carlsbad, CA 92010 CSA C22.2 No. 218.1 1.800.822.7933 | Jandy.com Zodiac Pool Systems Canada, Inc. ©2020 Zodiac Pool Systems LLC. All rights reserved. ZODIAC® 3365 Mainway, Unit 2 is a registered trademark of Zodiac International, S.A.S.U., used...
