Page 22
NOTE The DIP switches are monitored constantly, if they are changed
the system knows immediately. However, you can reset the
system to make sure that all of the screens get updated.
6.1 DIP Switch Functions
S1 DIP #1 ON - AUX 1 Controls Pool Cleaner
If a booster pump is installed for a pool cleaner, the relay coil for the booster
pump must be plugged into the AUX 1 relay socket. If a non-booster pump
cleaner is installed, plug the JVA into the cleaner JVA socket. Turn ON DIP
Switch #1.
Main filter pump turns on whenever cleaner turns on.
Cleaner will not turn on until filter pump has been on for
three (3) minutes (to ensure priming of system).
Cleaner turns off when water circulation is to spa.
Cleaner turns off when spa spillover feature is activated.
Cleaner turns off for three (3) minutes when solar is
activated (to ensure air is purged from the system).
AquaLink
rather than "AUX 1".
S1 DIP #2 ON - AUX 2 Controls Low Speed of Spa Pump
Turn this switch ON if you want to control both speeds of a two-speed spa
pump. With this switch on, the spa pump button on the AquaLink RS Control
Panel will control high speed and the AUX 2 button will control low speed.
IMPORTANT You must also install a Jandy
S1 DIP #3 ON - Not Used
S1 DIP #4 ON - Heater Cool Down Disabled
Turn this switch ON to disable the heater cool down safety feature on the
AquaLink RS.
Turn this DIP Switch ON only if you are using an
electric heater or a heat pump that does not retain
residual heat. If you are turning this switch ON for
service purposes, be sure to turn it back off.
S1 DIP #5 ON - Factory Use Only
This switch is used for calibration by Zodiac
leave this switch in the OFF position.
RS Control Panel display reads "CLEANER"
®
CAUTION
Jandy
AquaLink
®
Two- Speed Relay.
®
®
certified technicians only. Please
RS Conversion Kit
®
