Installation & Operation Manual
S1 DIP #6 ON
When OFF a separate heater is used for the pool and spa. When ON the pool
and spa share the same heater.
S1 DIP #7 ON
Change air sensor to solar sensor - Air temperature no longer displayed.
Adjustable Freeze Kit must be added for freeze protection.
S1 DIP #8 ON - Heat Pump Instead of Gas Heater
Turn this switch ON if you have installed a heat pump instead of a gas heater.
After thermostat setting has been reached, heater will remain OFF for 5
minutes.
S2 DIP #1 ON - Heat Pump Priority
This switch is used for configuring solar priority or heat pump priority. Set this
switch to ON if Heat Pump Priority will be used. Set this switch to OFF if Solar
Priority is to be used.
AquaLink RS Conversion Kit available accessories
All Button Indoor Controller
OneTouch Indoor Controller
Wireless Remote (AQWHR18 dedicated water resistant)
4 Button Spa-Side (7443, 8050, 7444)
10 Button Spa-Side (7227, 7887, 7888, 7940)
6.2 DIP Switch Settings
S1 DIP
Switch #
AUX1= any equipment
1
AUX2= any equipment
2
NOT USED
3
4
Heater cool down
operates.
Normal operation
5
6
Separate Pool and Spa
heater.
OFF
ON
AUX1= Pool Cleaner
AUX2= Low Speed for a
two-speed filter pump.
Filter pump circuit becomes
High Speed.
NOT USED
Heater cool down disabled.
Factory adjustment-
when this switch is on,
temperature delays are
eliminated and solar
temperature is displayed.
Do not leave this switch
in the ON position.
Sharing one (1) heater for
pool and spa.
Page 23
