SECTION 4 - SPECIFICATIONS AND APPROVALS
4.1 Specifications
For more information on sizing, see our Commercial Sizing Calculator on our website at
https://apservicecenter.com/sizing
Model Designation
Max. Chlorine Output w / PPC5 Cell
(lbs/day)
Max. Chlorine Output w / Convection
Cell (no manifold) (lbs/day)
Rated Power in AC Amps
Minimum Water Flow Rate (gpm)
Maximum Water Flow Rate (gpm)
ORP Input (Dry contact)
Weight (Power Supply)
Weight (Manifold)
Convection Cells
4.2 Manifold Pressure Drop vs Flow
The following chart shows pressure drop versus flow for Pool Pilot
PPP-2
5.24 lbs/day
(2.38 kg)
4.53 lbs/day
(2.05 kg)
230 V/4.4 A
10 mA typical (ORP controllers with 110 V output and multiple power supplies will
require relay kit part #110-ORP: ORP Relay Box (110V US plug)
83 lbs.
10 lbs.
10 lbs.
®
Pool Pilot
Professional Manifold Pressure Drop vs. Flow
PPP-3
PPP-4
7.86 lbs/day
10.48 lbs/day
(3.57 kg)
(4.75 kg)
6.79 lbs/day
9.06 lbs/day
(3.08 kg)
(4.11 kg)
230 V/6.6 A
230 V/8.8 A
30 – 50 gpm (6.8 – 11.3 m³/hr)
70 gpm (22.6 m³/hr)
91 lbs.
99 lbs.
20 lbs.
20 lbs.
15 lbs.
20 lbs.
PPP-5
13.1 lbs/day
15.72 lbs/day
(5.94 kg)
(7.13 kg)
11.32 lbs/day
13.59 lbs/day
(5.14 kg)
(6.16 kg)
230 V/11.0 A
230 V/13.2 A
107 lbs.
30 lbs.
25 lbs.
®
Professional manifolds.
Figure 4
PPP-6
115 lbs.
30 lbs.
30 lbs.
