RS48-11C ROLL 'n' SPIKE GOLF GREENS ROLLER - Operation, Maintenance & Parts Manual
rollers
When you receive the crate, the machine will be broken down into components ready for assembly. If you
run into any problems during assembly, please feel free to call your local distributor or agent.
QTY
1
Operation, Maintenance & Parts Manual
1
Machine Frame/Body
1
Drivers Seat
4
M8x20 Bolts
2
Tires mounted on Wheel Rim
1
Steering Joystick
1
Dampener Strut
INITIAL ASSEMBLY
List of Components
Description
(attached to main body end)
QTY
1
Left-side Trailer Arm
1
Right-side Trailer Arm
2
22mm External Circlips
1
Drawbar Coupling Assembly
2
2 1/4" x 3/8" UNF Hex Head Bolts
2
3/8" UNF Nyloc Nuts
Description
