MAINTENANCE

• Stop engine before performing any maintenance
• Service the Honda or Kohler engine according to the manufacturers maintenance schedule.

TRANSMISSION (PUMP, EATON 11)

• Initially, change the oil at 50 hours running time, then;
• Change oil every 500 hours or annually, whichever occurs first
• Change hydraulic oil filter every 500 hours or annually, whichever occurs first.
• Only use the manufacturer's recommended replacement oil filter
• When fitting the filter, follow the instructions supplied with the filter. This will ensure that the filter
remains tight and that no leaks occur
• Check all hard line oil pipes for rubbing, excessive vibration, leaks and tightness on a regular
basis
• Check transmission oil level on oil tank sight glass. Oil level should remain at a minimum of 25mm
(1") and at a maximum of 40mm (1.5") from the top of the tank
• Oil Capacity including filter is 6 liters or 5.3 U.S. quarts
• As a guide to correct transmission oil, see page 1 of this manual.

STORING

• It is important to store this roller in the towing position. This ensures the trailer strut is in the
closed position, protecting the shaft from corrosion, then failure & that the weight is taken off the
roller bearings.
SERVICE OF THE DRIVE CHAIN SYSTEM
• Replacement - Use only the chain and sprockets recommended as per the correct spare parts
number. Wrong pitch drive chain fitted will cause excessive sprocket wear & possible drive failure.
• Tensioning the drive chain - No adjustment is required; the chain tension is automatically
