RS48-11C ROLL 'n' SPIKE GOLF GREENS ROLLER - Operation, Maintenance & Parts Manual
rollers

ROLLER WILL NOT MOVE ONE OR EITHER WAY

Check: •
•
•
•

ROLLER WILL NOT STEER

Check: •
•
•
•
•

ROLLER HAS EXCESSIVE VIBRATION

Check: •
•
•

SMOOTHING ROLLERS SEIZED

Check:
•

FAULT FINDING

Chain is okay
Sprockets are not worn or slipping on the shaft
Foot control is operating - check all arms are secure
For Sheared Sprocket Keys
Woodruff Key is in place & not sheared
Rod ends are connected to smoothing roller head and the steering arm
Centre swivel bearing on top centre of smoothing rollers have not seized
Connecting rod is in place & serviceable
Roller shaft bolts in the head centre have not worked loose and are locking.
Disconnect engine-to- transmission and isolate the drive chain to determine whether
the problem is in the engine or in the transmissions
If engine is at fault contact your nearest engine agent for rectification
If the transmission is at fault, repair or replace as necessary, or seek professional
advice from a local Eaton Service Center
Bearings have not seized
1
