RS48-11C USA GOLF ROLLER & SPIKER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS48-11C and is the answer not in the manual?

Questions and answers

Related Manuals for Tru-Turf RS48-11C

Summary of Contents for Tru-Turf RS48-11C

  • Page 1 RS48-11C USA GOLF ROLLER & SPIKER MANUAL...

  • Page 2: Table Of Contents

    3. Safety Information 4. Warranty 5. Assembly 8. Operation 10. Maintenance 12. Fault Finding 13. Machine Components 25. Options 26. Labels 27. Parts List Note: Separate Engine Owners Manual Included TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...

  • Page 3: Important

    Australian customers call 07 5594 7199. International customers contact your dealer or visit www.truturf.com to fi nd your nearest dealer. TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...

  • Page 4: Machine Information Record

    Greens. The following operation and maintenance manual has been prepared for use with the RS48-11C Roll ‘n’ Spike Golf Green Roller. It is intended as a guide and supplemental updates to the manual may take place at a future date, without prior notice.

  • Page 5: Safety Information

    When carrying out maintenance ensure the catch is engaged correctly; if it is not the trailer arm could fl y up making contact TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...

  • Page 6: Warranty

    Tru-Turf Pty. Ltd. will not repair or replace free-of-charge any item that has been damaged by accident, lack or part of a Tru-Turf Pty. Ltd. Golf Greens Roller that is of reasonable care and protection or lack of suitable defective in workmanship or material for a period of thirty six (36) months from the date of delivery of the storage.

  • Page 7: Assembly

    (attached to main body end) Left-side Trailer Arm Right-side Trailer Arm 25mm External Circlips Drawbar Coupling Assembly 2¹/2” x 3/8” UNF Hex Head Bolts (Drawbar) ³/8” UNF Nyloc Nuts (Drawbar) TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 8 Step 6: Attaching wheels to trailer arms. • Locate the two wheels for the left and right side trailer arms. TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 9 • The oil in the engine upon delivery (if not pre- TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...

  • Page 10: Operation

    By using the lubricant. left and right pedal in this manner, will ensure there is no damage to the green and less wear and tear on the equipment and operator. TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 11 • Ensure the park brake is released prior to operating the roller, if not irreparable damage to the rubber on the drive roller will occur. TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...

  • Page 12: Maintenance

    Oil Capacity including fi lter is 6 liters or 5.3 U.S. quarts. For the ultimate performance we use and recommend the Penrite synthetic 5 SAE 5W-60 transmission oil. (Part No. R5226) TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 13 Renew Drive Roller Bearings Changing transmission oil √ Renew Chain Tensioner Sprocket Bearings √ Renew Drive Chain • See page 12 and 14. Replace Foot Pedal Struts Replace Trailer Strut TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...

  • Page 14: Fault Finding

    Disconnect engine-to-transmission and isolate the drive chain to determine whether the problem is in the engine or in the transmissions. • If engine is at fault contact your nearest engine agent for rectifi cation. TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 15 Operating Positions R6019 Rolling Position R8024 R6056 R8274 R8025 R5009 R8026 R8007 Towing Position R5239 R5016 R6015 TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 16 R5071 R9012 R5061 R8299 R6013 R6013 Bottom View R8060 R5012 R5075 R8005 R5075 R8001 R5156 R8060 R5012 Foot Control R5014 R6054 R5013 R6006 R5159 R5142 R5113 R5112 R8000 Top View TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 17 R6054 R5277 R5144 R5013 R5148 R6006 R5143 R5231 R5232 R5197 R5234 R6015 Top View R5233 R5132 R5230 R5234 Oil Line Fittings Chain Tensioner R8013 R5147 R5145 R8011 Top Rear View TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 18 Oil lines R5228 R5178 R5154 R5152 R5153 R5233 R5227 R5233 Oil Lines R5153 R5154 R5239 R5229 R5228 R5178 R5233 R5152 R5277 R5153 R5233 R5016 Oil Lines TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 19 Transmission & yoke R5131 R5133 R5033 R5108 R5089 R5173 R5173 R5139 R5156 R5031 R9028 R8210 R5046 R5140 R8218 R8047 R8256 R8005 R5171 R8060 R5156 R5118A R5184 R5118A TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 20 Transmission & chain tensioner R5133 R5131 R9003 R5156 5/16 Set screw R9004 R9005 R8055 1/4 x 3/4 UNC bolt R5132 R9007 R9007 R5094 R5099 R5132 R5095 TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 21 R5060 R5057 R5058 R5069 R5087 R5059 R5238 R5013 R5240 R5014 R5189 R5064 R5065 R5189 R5066 R5064 R5056 R5065 R5189 R5064 R5189 R5062 R5238 R5059 R5069 R5058 R5068 R5060 R5070 R5057 TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 22 The 1/2” size for the steer & smoothing roller connecting rods applies from serial number R10923 onwards. R8287 R8287 R8285 R8220 Tube R8286 Rod R8283 1/2” R6004 R6005 R8011 Pivot arm & smoothing head TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 23 R8020 R8014 R8014 R8015 R8015 R5113 R5113 R8016 R8016 R5208 R5211 R5209 R8017 R8021 Smoothing head & components (This style smoothing roller for use on machines preceding serial number R10832) TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 24 Engine with base & seat with base R5140 R9001 (Honda 6.5 hp) R5031 R5195 R5085 R5142 R5142 R5149 R5142 R5142 R5085 Engine & base R8026 R8025 R8275 R8024 R5016 Seat & base TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 25 R6056 R6009 R9017 R5156 R8060 R8018 Joystick & steering shaft (This 1/2” size for the steering arm bolt, steer & smoothing head connecting rods applies from serial number R10923 onwards) TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 26 Trailer frame & components R6019 R8008 R5049 R8002 R6001 R5210 R8009 R9037 (Complete) R9037 R9036 R9035 R6039 R9034 R9033 R9032 R9030 R9030 R9029 TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...

  • Page 27: Options

    Options E7045 R8292 (Kit Complete) E7067 R8270 (Wire Harness) R8029 ( Brush Kit) R5226 R5020 TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...

  • Page 28: Labels

    Labels R8010 R6025 R6024 R6023 R6022 R6057 R6059 R6058 R6040 R6041 TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...

  • Page 29: Parts List

    Fitting; 90 deg Elbow F-8 JIC SWIVEL to M-8 JIC (G-J-90-1212) R5112 Circlip; External 25mm R5236 Plug; Plastic 1”x1” R5113 Washer, Flat, 24x44x2 mm R5238 Plug; Plastic 1 1/4” x 1 1/4”; Trailer 19, 20 TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
  • Page 30 Harness; Wire R8024 Seat; Michigan 13, 22 R8029 Brush, Nylon 1000mm x 100mm R8025 Armrest RH 13, 22 R8292 LED Light Kit if fi tted with R8275 Seat Base Plate TRU-TURF RS48-11C USA Roll ‘n’ Spike Golf Greens Roller Manual...
