RS48-11C ROLL 'n' SPIKE GOLF GREENS ROLLER - Operation, Maintenance & Parts Manual
rollers
PART NO. PAGE NO.
R8001 18
R8002 28
R8003 24
R8004 24
R8005 18,21
R8006 24
R8007 17
R8008 28
R8009 28
R8010 30
R8011 19,24
R8012 26
R8013 19
R8014 25
R8015 25
R8016 25
R8017 25
R8020 25
R8021 25
R5119 29
R5120 29
R5121 29
R5122 29
R5123 29
R5124 29
R5125 29
R5126 29
R5127 29
DESCRIPTION
Foot Pedals Tapered
Trailer Arm LH
Smoothing Head Pivot Frame
Smoothing Head Pivot Bush Holder
Foot Pedal Arm Tapered
Bush Bronze Smoothing Head Pivot 20x26x30
RS48-11C Transmission Cover
Trailer Arm RH
Bush Bronze Trailer Arms 25x32x30
Naming Plate RS48-11C
Ruber Buffer, Pivot Frame
Engine Honda 6.5HP
Housing; Filter; Tank; Transmission Oil
Circlip; Smoothing Rollers
Washer; Smoothing Roller 25X52X3
Bearing; 6205 Stainless Steel
Shaft; Smoothing Roller Suites Tube R8020
Tube; Smoothing Roller with Circlip R8014
Tube; Complete Kit
OPTIONS AVAILABLE
Light 2 Off (50W)
Coil; Lighting; for Honda 4.0 hp & 5.5hp
Flywheel, Honda 5.5hp
Bolt; Flange
Switch; Light
Harness; Wire
Bracket; Lights; for Light Kit
Bracket; Switch; for Light Kit
Light Kit; Complete
