Tru-Turf RS48-11C Manual page 34

RS48-11C ROLL 'n' SPIKE GOLF GREENS ROLLER - Operation, Maintenance & Parts Manual
rollers
PART NO. PAGE NO.
R5087 23
R5089 21
R5094 22
R5095 22
R5099 22
R5108 21
R5109 21
R5111 21
R5112 18
R5113 18,25
R5114 21
R5118 21,24,25,27
R5129 19
R5131 21,22
R5132 19,22
R5133 21,22
R5136 22
R5137 22
R5138 22
R5139 21
R5140 21,26
R5141 18,23
R5142 18,26
R5143 19
R5144 19
R5145 19
R5147 19
R5148 19
R5149 26
R5152 20
R5153 20
R5154 20
R5156 18,21,22,27
R5158 19
R5159 18
R5162 26
R5164 18,21,23
R5168 21
DESCRIPTION
Key, Woodruff 8x30
Key; Woodruff 3/16"
Spring; Arm; Chain Tensioner
Washer; Capped
Bush; Bronze; for Chain Tensioner Arms
Ball Fitting; Small Flange
Clip; Retainer
Clip; Retainer
Circlip; External 25mm
Washer, Flat, 24x44x2 mm
Cup; End Short
Rod End
Meter; Hour/Tach
Bracket; Transmission; Eaton 11
Arm; Chain Tensioner
Transmission; Eaton 11
Sprocket; 11 Tooth; Duplex
Chain, Duplex; Eaton 11 Transmission
Joiner; Chain; Duplex Eaton 11 Transmission
Coupling; Transmission; Eaton 11 Honda 5.5hp or Kohler 6hp
Coupling; Engine; Honda 5.5hp or Kohler 6hp
Sprocket; 27tooth; Duplex; Drive Roller; Eaton 11 Transmission
Cushion; Rubber; for Engine Base Plate
Tank; Stainless Steel; Transmission Oil
Breather; Tank; Transmission Oil
Plug; Drain; Tank; Transmission Oil
Cartridge; Filter; Tank; Transmission Oil
Gauge; Sight; Tank; Transmission Oil
Plate; Mounting; Engine
Pipe; Oil
Pipe; Oil
Pipe; Oil
Key; Woodruff; 1/8" x 5/8"
Rubber Strip; Frame; Seat
Rubber Strip; Rest; Trailer
Engine; Kohler; 6 hp
Key; Woodruff; 4 x 6.5mm
Spacer; Stainless Steel; Strut End; Transmission
