S6C - S6C HP PUMPS
Z.I. La Plaine des Isles - F 89000 AUXERRE - FRANCE
Tel. : +33 (0)3.86.49.86.30 - Fax : +33 (0)3.86.49.87.17
contact@mouvex.com - www.mouvex.com
INSTALLATION
MAINTENANCE
Your distributor :
3, Poruchik Nedelcho Bonchev Str., . 5,1528 So a, Bulgaria
tel: +359 2 973 27 67
e-mail: o ce@daisglobal.eu
INSTRUCTIONS 1002-C00 e
Section
1002
Effective
November 2011
Replaces
October 2010
Original instructions
OPERATION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOUVEX S6C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PSG MOUVEX S6C

Summary of Contents for PSG MOUVEX S6C

  • Page 1 INSTRUCTIONS 1002-C00 e Section 1002 Effective November 2011 Replaces October 2010 Original instructions S6C - S6C HP PUMPS INSTALLATION OPERATION MAINTENANCE Your distributor : 3, Poruchik Nedelcho Bonchev Str., . 5,1528 So a, Bulgaria Z.I. La Plaine des Isles - F 89000 AUXERRE - FRANCE tel: +359 2 973 27 67 Tel.

  • Page 2: Table Of Contents

    ECCENTRIC PISTON MOUVEX PRINCIPLE SAFETY, STORAGE, INSTALLATION AND MAINTENANCE INSTRUCTIONS S6C - S6C HP MODELS TECHNICAL CHARACTERISTICS USED PRESSURE UNITS • Maximum speed : 530 rpm Unit without suffix : • Range of acceptable temperature : Differential pressure, for example, pressure difference between EPDM : equipment suction and discharge.

  • Page 3: Overall Dimensions

    1. OVERALL DIMENSIONS Weight : 62 kg Pump plate POSITION OF THE ORIFICES Orifices Connection Standards Suction 1 - 3 - 5 1 to 8 Discharge Dimensions in millimetres NT 1002-C00 11.11 S6C S6C HP Pumps e 3/12...

  • Page 4: Installation

    2. INSTALLATION CAUTION 2.1 Fixing to the ground of non-mobile units The base plate is equipped with 3 fixed legs (height 92 mm) + 1 screw jack leg, all fixed under the base plate. FAILURE TO RELIEVE SYSTEM PRESSU- These legs are made of an identical substance to that of RE PRIOR TO PERFORMING PUMP SERVI- the base plate.
  • Page 5 2. INSTALLATION (continued) The unit’s base must be flat, level and sufficiently resis- The 3 figures below show in detail the operation and the tant to absorb the stresses caused by the motor-driven possible defects : pump unit without deformation (if it is made of concrete, it must comply with the BAEL 91 standard).

  • Page 6: Use

    2. INSTALLATION (suite) WARNING 2.5.4 THERMIC MOTORS CAUTION IT IS IMPERATIVE THAT THE HYDRAULIC PRESSURE IS RELEASED BEFORE EACH MAINTENANCE OPERATION TO AVOID PERSONAL INJURY MATERIAL THE SURFACES CAN BE AT A TEMPERA- Hazardous pressure DAMAGE TURE LIABLE TO CAUSE INJURY OR can cause SEVERE DAMAGE.

  • Page 7: Clean In Place (Cip) & Sterilisation In Place (Sip)

    4. CLEAN IN PLACE (CIP) & STERILISATION IN PLACE (SIP) 4.1 Preamble 4.2 Cleaning Out of place S-Series pumps have been designed to permit an easy Please refer to the § ASSEMBLY / DISMANTLING of the cleaning with CIP procedure. However, this cleaning might pump, while taking care to avoid any dropping or any not be compliant with some high hygienic standards and bumping of the parts as this could damage them.

  • Page 8: Sterilisation In Place (Sip)

    4. CLEAN IN PLACE (CIP) & STERILISATION IN PLACE (SIP) (continued) 4.4 Sterilisation In Place (SIP) The centrifugal pump delivering the washing solution is generally calibrated to a higher troughput than 10 m The serie S pumps are perfectly adapted to all pro- therefore a pump bypass circuit must be provided for cesses using SIP (Sterilisation In Place): pump (see fig.3).

  • Page 9: Assembly / Dismantling

    5. ASSEMBLY / DISMANTLING WARNING WARNING DISCONNECTING THE FLUID OR PRESSU- TAKE ALL NECESSARY MEASURES TO CONTAINMENT COMPONENTS RENDER ANY START-UP, EVEN ACCIDEN- DURING PUMP OPERATION CAN CAUSE TAL, OF THE PUMP DURING THE WORK SERIOUS PERSONAL INJURY, DEATH OR IMPOSSIBLE.

  • Page 10: Opening The Pump

    5. ASSEMBLY / DISMANTLING (continued) 5.2 Opening the pump 5.4 Remounting the transmission block Disconnect the pump from the discharge pipe. Proceed in the reverse order from the preceding chapter taking care to correctly orient the main body 101. Remove the base 401 : unscrew the 8 nuts 106. All screws must be degreased and mounted with a Remove the pressure of the spring 311 by pushing it medium thread locking adhesive (LOCTITE...

  • Page 11: Maintenance

    6. MAINTENANCE 6.2 Checking of seals During all dismantling and re-mounting operations, takecare to protect the parts against any dropping or bumping that Seals material are intended for use in normal conditions might damage them. in food process. In order to ensure a reliable sealing on S series pumps we recommend to : 6.1 Checking of parts - do an inspection of the seals every three months (this...

  • Page 12: Certificate Of Conformity

    7. CERTIFICATE OF CONFORMITY CERTIFICATE OF CONFORMITY MOUVEX, Z.I. La Plaine des Isles - Rue des Caillottes - 89000 AUXERRE FRANCE, declares the following equipment : Set-up : Pump / Compressor « bare-shaft » Pumping Unit / Compressor Unit Type : Eccentric Disc Pump Vanes Pump Lobes Pump...
