- Page 1 APP 9005C Service Power Supply Installation and Operation Manual Effective: August 2019...
- Page 2 Alpha tries to adhere to ANSI Z535 and encourages special attention and care to information presented in the following manner:...
- Page 3 Alpha Technologies Services, Inc. or your nearest Alpha representative. Alpha shall not be held liable for any damage or injury involving its enclosures, power supplies, generators, batteries, other hardware, or software if used or operated in any manner or subject to any condition not consistent with its intended purpose or is installed or operated in an unapproved manner or improperly maintained.
-
Page 4: Table Of Contents
2.1 APP 9005C Installation Procedure ........ -
Page 5: Safety Precautions
(400 Amp, no-trip, first-half cycle). Do not replace this breaker with a conventional service entrance breaker. Alpha recommends only Airpax breakers because of increased reliability in this powering application. 016-562-B0-001, Rev. A (08/2019) -
Page 6: Introduction
8 hours while the existing node is being optimized on site prior to connecting it to the network and carrying traffic. The APP 9005C SPS contains a front panel ammeter to measure the output current to the load, dual 90V outputs with an auto-seize mechanism, and an “Output”... -
Page 7: App Service Power Supply Features
Power Switch The AC power switch turns on or shuts off power to the APP 9005C SPS. If the unit does not turn ON when power is applied, first verify that the unit is plugged into the convenience outlet and that all circuit breakers are in the ON position. -
Page 8: Installation
Plug the APP 9005C line cord into a portable generator (Honda EU2200 recommended) or 120VAC utility outlet. Connect the coax from the remote PHY unit to the APP 9005C (PHY unit not supplied). If the Output Power Indicator illuminates while the Input Breaker/Power Switch is in the OFF position, this indicates there is power back-feeding from another power source via the Output Connector. -
Page 9: Troubleshooting
3.1 Troubleshooting Guide This guide is designed to cover typical problems, causes and solutions for troubleshooting the APP 9005C SPS. Alpha recommends that the power supply maintenance log accompany units brought in for bench service to aid the technician in troubleshooting the problem. -
Page 10: Returns, Repair, And Parts Ordering
3.0 Troubleshooting, continued 3.2 Returns, Repair, and Parts Ordering Returns for Repair For units that must be returned for repair, Alpha requires a Return Material Authorization (RMA). An RMA can be obtained from Alpha Customer Service, using either method listed below: •... - Page 11 Alpha Technologies Services, Inc Alpha reserves the right to change specifications without notice. © 2019 Alpha Technologies Services, Inc. All Rights Reserved. Alpha is a registered trademark of Alpha Technologies Services, Inc. an EnerSys company 016-562-B0-001, Rev. A (08/2019) For more information visit www.alpha.com...
