Celestron RASAv2 11" (22mm bore)
•
Celestron RASA 14" (22mm bore)

Warranty

We provide 1-year warranty for our products. We will offer the repair service for free or replace the item for free if the unit does
not work properly within the warranty period. After the warranty period, we will continue to provide repair support and service
on a charged basis. This warranty does not apply to damage that occurred because of abuse or misuse, or damage caused by a
fall, or any other accidental failures after purchase. The customer must pay for shipping when shipping the camera back for
repair or replacement. If you get a faulty unit, please contact us as soon as possible through email: support@pegasusastro.com
Please describe the problem in detail, and we will do our best to solve the problem. Most instances are perceived problems
which are caused by a bad driver install or software configuration.

Technical Specifications

Supply Voltage
Motor Compatibility
Motor Output
Motor Specification
USB Connectivity
Thermal Sensor Resolution
Power Input Connector
Dimensions
DC 12V – 13.8V / 1Amp
Stepper Motor is inside the enclosure
None (Stepper Motor is in the enclosure)
High resolution geared stepper motor
(Step Angle (Deg) 7.5 / 120
(Gearbox reduction rate = 0.06255 Deg).
5755 steps per circle of rotation.
* Firmware implements half step drive so one motor cycle is:
5755 x 2 = 11510 steps
USB 2.0 Type B plug
9-bit Celsius temperature measurements – External Sensor with RJ45 plug
2.1mm Centre Positive Socket
56mm x 63mm x 39 mm / 300 grams
