Operating Instructions:
•
Plug the temperature sensor to the RJ45 socket.
•
Plug the supplied USB type B cable to the device.
•
Plug DC 12V/1-2Amps power cable into the DC 2.1mm socket.
•
Device will boot and after three seconds the green indication LED will turn ON. This means that firmware was loaded
successfully and the "FocusCube v2" is now fully operational.
•
Download USB drivers, standalone software or ASCOM drivers from
device.
Focuser Compatibility (Universal Bracket)
We have successfully installed our Universal L shape bracket on:
•
Takahashi TSA120
•
Takahashi FS60
•
Takahashi FSQ85
•
Takahashi FSQ106
•
Skywatcher Esprit Series (80 ED, 100ED, 120ED, 150ED)
•
Skywatcher PDS 130
•
Explore Scientific ED Series (ED80, ED102, ED127, ED152)
•
Explore Scientific ED-FCD100 Series (ED80-FCD100, ED102-FCD100, ED127-FCD100)
•
Explore Scientific FPL53 (ED140, ED115)
•
Feathertouch Focuser 2.5''
•
Feathertouch Focuser 3"
•
Feathertouch Focuser 3.5"
•
Vixen VC200L
•
Altair Wave Series Telescopes (All models)
•
Celestron SCT C 6,8,9.25,11,14
•
Celestron SCT Edge 6,8,9.25,11,14
•
Celestron RASA 8,11
•
Orion ED80T
Focuser Compatibility (SCT Bracket)
A special shaped black anodised aluminium bracket, hard to bend, can be attached to most of the Celestron SCT telescopes. We
provide three SCT versions. The difference is in the metal pulley bore diameter & the screw length in the package. Make sure
you have selected the correct type.
•
Celestron EdgeHD 8, 9.25 , 11, 14 (13mm bore)
•
Celestron SCT C6, C8, C925, C11, C14 (22mm bore)
•
Celestron RASA 8 (13mm bore)
pegasusastro.com/support in order to connect to the
