4 Press and hold
settings to the target radio. If cloning was successful, P or Pass displays on the source radio and
the target radio displays all feature icons. If cloning was not successful, F or Fail displays on the
source radio.
5 Turn the target radio OFF and back ON again to use.
6 To clone another radio, repeat steps 3 and 4.
7 To exit programming mode on the source radio, press and hold Push to Talk until
longer appears.
1.8

Troubleshooting

When and where to use: When troubleshooting, always observe the color of the LED:
Table 4: Charger LED Indicator
Status
Power On
Charging
Charged
Error*
Standby**
Battery Level Status
*Normally, re-positioning the battery pack will correct this issue.
** Battery temperature is too warm or too cold or wrong power voltage is being used.
Procedure:
1 If there is NO LED indication, check that the radio, or stand-alone battery, is inserted correctly.
2 Ensure the power supply is plugged into an appropriate AC outlet. (for CLS Single Unit Charger
(SUC) Tray only).
3 Ensure the USB connector of the power supply is plugged securely into the charger socket (for
CLS Single Unit Charger (SUC) Tray only).
4 Ensure the power cord is plugged securely into the charger socket with an appropriate AC outlet
and there is power to the outlet (for CLS 6-Pocket Multi-Unit Charger Tray only)
5 Confirm that the battery used with the radio is Motorola Solutions authorized batteries listed in
Table 1.
on the source radio. The source radio enters cloning mode and transmits its
LED Status
Green for approx. 1
sec
Steady red
Steady green
Red fast flash
Amber slow flash
Flash red 1 time
Flash amber 2 times
Flash green 3 times
