NetVanta 3205
®
Modular Access Router Supporting up to Two T1s of Bandwidth
Physical Interface
NIM: 56/64k, T1/FT1, T1/FT1 with DSX-1, Dual T1,
■
E1/FE1, E1/FE1 with G.703, ADSL, SHDSL, and Serial
DIM: Analog Modem and ISDN BRI (U and S/T)
■
LAN: Auto-sensing 10/100Base-T Full Duplex (RJ-45)
■
Console Port
■
Diagnostics LEDs
Power
■
WAN: link, transmit, receive
■
LAN: link, transmit, receive
■
Dial backup: transmit and receive
■
Processor and Memory
Motorola MPC 866
■
120 MHz
■
Security
Firewall
Stateful Inspection Firewall
■
Denial of Service (DoS) Protection
■
Access Control Lists
■
Application Level Gateways (ALGs)
■
Network Address Translation
Basic NAT (1:1), NAPT (Many:1), and 1:1 Port Translation
■
NAT-compatible SIP ALG
■
Secure Management
Multi-level access control
■
RADIUS AAA
■
TACACS+
■
SSH CLI and SSL GUI
■
Port Authentication (802.1x)
■
Optional Virtual Private Network (VPN)
IPSec Tunnel Mode: 5 Tunnels
■
Encryption: DES, 3DES, and AES
■
Diffie Hellman Group Support:
■
Group 1: MODP 768
❍
Group 2: MODP 1024
❍
Hash Algorithms: MD5-HMAC and SHA1-HMAC
■
Authentication Mechanisms:
■
XAUTH
❍
X.509 Digital certificates
❍
Preshared keys
❍
Key Management: IKE (ISAKMP/Oakley)
■
IKE Modes:
■
Main
❍
Aggressive
❍
Dead Peer Detection
■
NAT Traversal V2
■
Quality of Service (QoS)
Class-based Weighted Fair Queuing, Low Latency, and
■
Weighted Fair Queuing
DiffServ Packet Marking and Recognition
■
Frame Relay Fragmentation
■
ADTRAN believes the information in this publication to be accurate as of publication date, and is not responsible for
error. Specifications subject to change without notice. ADTRAN and NetVanta are registered trademarks of ADTRAN, Inc.
and its affiliates in the U.S. and certain other countries. All other trademarks mentioned in this document are the property
of their respective owners. Five-year warranty applies only to products sold in North America.
ADTRAN products may be subject to U.S. export controls and other trade restrictions. Any export, re-export, or transfer
of the products contrary to law is prohibited. For more information regarding ADTRAN's export license, please visit
www.adtran.com/exportlicense
Secure ID
❍
DSS Signatures
❍
Perfect Forward Secrecy
❍
Mode Config
❍
Protocols
eBGP/iBGP PPP
■ ■
OSPF PPPoE
■ ■
RIP (v1 and v2) PPPoA
■ ■
Demand Routing RFC 1483
■ ■
GRE Multilink PPP
■ ■
IGMP v2 HDLC
■ ■
ATM (ADSL) PPP Dial Backup
■ ■

Frame Relay

PAP and CHAP
■ ■
Multilink Frame Relay Multihoming
■ ■
Frame Relay
Point-to-point
■
RFC 1490 Encapsulation (Multiprotocol Over
■
Frame Relay)
LMI types: LMI, ANSI (Annex D), CCITT (Annex A)
■
and Static
DHCP
Client, Server, and Relay
■
Administration
Familiar Command Line Interface (CLI)
■
Web-based GUI SYSLOG logging
■ ■
n-Command support Email alerts (SMTP)
®
■ ■
SNMP v3 Policy statistics
■ ■
Environment
Operating Temperature: 0° to 50 °C (32° to 122 °F)
■
Storage Temperature: -20° to 70 °C (-4° to 158 °F)
■
Relative Humidity: Up to 95%, non-condensing
■
Physical
Chassis: 1U, rackmountable metal enclosure
■
Dimensions: 1.25" H, 17.25" W, 7.75" D
■
Weight: 7 lbs.
■
AC Power: 100-250 VAC, 50/60 Hz,
■
6W max. (1202870L1)
DC Power: -48 +24 VDC, 6 W max. (1200980L1)
■

Agency Approvals

FCC Part 68
■
Industry Canada CS03
■
UL and Canadian UL (CUL), IEC/EN, CSA
■
CE Mark
■
RoHS ("E" versions)
■

Ordering Information

Equipment
Systems
NetVanta 3205 Chassis DC (NEBS III)
NetVanta 3205 Chassis AC
with 56/64k NIM
with T1/FT1 NIM
with T1/FT1+DSX-1 NIM
NetVanta 3205 Chassis with VPN
VPN Software Upgrade
Part #
1202980L1
1202870E1
4200871L1
4200872L1
4200873L1
4200870E2
1950860E2
