Summary of Contents for Tele System TS6700 T2HD
-
Page 2: Table Of Contents
INDEX Safety regulations ............................1 Product description and connections ......................2 Front Panel ............................2 Rear panel and connections ........................ 2 Remote Control Unit ..........................3 2.3.1 Batteries ............................3 ... -
Page 3: Safety Regulations
TELE System TS6700 HD 1 Safety regulations We advise you to read the following advice concerning the safety regulations carefully in order to ensure safe use of the appliance. ELECTRICAL SUPPLY The appliance should only be supplied by a current of 230 Volt AC, 50Hz. -
Page 4: Product Description And Connections
TELE System TS6700 HD 2 Product description and connections 2.1 Front Panel 1. USB PORT 2. Power/Standby LED Indicator 3. IR Receiver Sensor 4. CH▼ Button 5. CH▲ Button 6. Power/Standby Button CAUTION It’s not guarantee the compatibility with all USB mass storage devices of the market. -
Page 5: Remote Control Unit
TELE System TS6700 HD 2.3 Remote Control Unit 2.3.1 Batteries Information and warnings Battery type: 2 x AAA, 1.5V. Insert/replace the batteries at the first installation or when the remote control doesn’t work well. It’s recommended to remove batteries from the remote control if it is not used for long time, in order to avoid any possible damage. -
Page 6: First Time Installation
TELE System TS6700 HD 3 First time installation When all the connections on the receiver are ready (section 2.2) and the mains lead is plugged in, the receiver will start up automatically. If this does not happen, press the q button on the front panel of the receiver or on the remote control. -
Page 7: Receiver Menu
TELE System TS6700 HD 4 Receiver Menu The first time installation procedure (chapter 3) will allow the receiver to be used with its basic functions. However the receiver offers many more advanced features and options that are illustrated in the following sections. -
Page 8: Edit Channel
TELE System TS6700 HD 4.1.2 Edit Channel Move cursor to “Edit Channel” and press [OK] button to enter in its submenu. There are 3 options which are listed below. l TV Channel List Open TV Channel List. On the left is the list of all TV channels or free channels, on the right is a visible small window for viewing the selected channel, and at the bottom is the navigation guide for all operations. -
Page 9: System Setup
TELE System TS6700 HD 4.1.4 System Setup Move cursor to “System Setup” and press [OK] button to enter in its submenu. There are 12 options which are listed below. Use [CH▲/▼] buttons to select submenu and press [OK] to enter in its interface, press [EXIT] button to quit. -
Page 10: Tools
TELE System TS6700 HD Jump: 30 sec/1 min/ 5 min/ 10 min/ 30 min Timeshift to Record: ON/OFF PS Record: ON/OFF NOTE Tips for record real-time channel program Connect USB device with receiver. Turn on “Time Shift” mode. Press [PAUSE] button to stop the TV program and the receiver will start recording as much as the USB device capacity is. -
Page 11: The Menus
TELE System TS6700 HD 5 The menus The menu map: Main Menu ▼ Media Player Edit Channel Installation System Setup Tools ▼ ▼ ▼ ▼ ▼ TV Channel list DVBT Installation Language Information Video Radio Channel list TV system Factory Setting... -
Page 12: Problem Solver
TELE System TS6700 HD 6 Problem solver PROBLEM POSSIBLE CAUSE REMEDY Make sure the mains lead is properly 1. The receiver does not start (the The mains lead is not plugged in. plugged in. LED on the front panel display is not... -
Page 13: Technical Specifications
TELE System TS6700 HD 7 Technical Specifications Product type Free to air digital terrestrial receiver DVB-T2 HD with USB Input frequency range 177,5÷226,5 MHz (VHF) / 470÷858 MHz (UHF) 7 / 8 MHz Bandwidth – Front Panel Display Menu language... - Page 14 TELE System TS6700 T2HD CE conformity declaration Tele System Electronic states that this product meets the basic requirements of the European directives 2009/125/EC (Energy related Products - ErP), 2004/108/EC (Electromagnetic Compatibility - EMC) and 2006/95/EC (Low Voltage Directive - LVD), following the technical standards: Electromagnetic compatibility: •...
