Indice Norme di sicurezza ............................. 2 Descrizione prodotto e collegamenti ......................3 Pannello frontale ..........................3 Pannello posteriore e connessioni ....................4 Telecomando ............................ 5 2.3.1 Batterie ............................ 5 2.3.2 Tasti e funzioni del telecomando ..................... 5 Primo avvio del ricevitore ..........................6 Impostazioni avanzate ..........................
TELE System 1 Norme di sicurezza Per un utilizzo sicuro dell’apparecchio, e per la vostra incolumità, leggere attentamente i seguenti consigli riguardanti le misure di sicurezza. ALIMENTAZIONE Il ricevitore deve essere collegato esclusivamente ad una presa di corrente da 230V~, 50Hz.
TS6512HD 2 Descrizione prodotto e collegamenti 2.1 Pannello frontale 1. USB Porta USB per lettura foto JPG, audio MP3, video MPEG2/MPEG4 e per registrazione da sintonizzatore digitale terrestre integrato. AVVERTENZE Compatibile con dispositivi di memoria USB formattati con file system FAT32.
TELE System 2.2 Pannello posteriore e connessioni AVVERTENZA È buona regola effettuare le connessioni del dispositivo con altri apparecchi (TV, VCR, HI-FI, etc.) e l’antenna prima di collegarlo all’alimentazione. Con il ricevitore in tensione è possibile infatti che, durante l’inserimento dei connettori, si creino differenze di potenziale elettrico in grado di generare correnti che possono danneggiare gli apparati.
TS6512HD 2.3 Telecomando La conoscenza del telecomando costituisce la base per l’utilizzo del ricevitore e per una facile navigazione tra le varie funzioni e i menu. 2.3.1 Batterie Informazioni ed avvertenze Sostituire o inserire le batterie al primo utilizzo del prodotto o quando il telecomando non risponde più...
TELE System 3 Primo avvio del ricevitore Una volta terminato il collegamento del ricevitore (par. 2.2), connessa la spina di alimentazione nella presa di rete elettrica e commutato l’interruttore 0/I del pannello posteriore in posizione I, il ricevitore si avvierà...
TS6512HD 4 Impostazioni avanzate La procedura di prima installazione (cap. 3) permette già l’utilizzo base del ricevitore. Esso presenta comunque potenzialità e personalizzazioni più avanzate che sono brevemente descritte nei paragrafi seguenti. 4.1 Password La modifica di parametri importanti del menu e l’accesso ad eventi protetti tramite Controllo Parentale (par.
TELE System 4.5 Regolazione orario Per attuare tale regolazione, premere il tasto MENU e selezionare il menu Configura Sistema - Imposta ora locale. Sono disponibili due modalità, distinguibili dal valore del parametro Uso GMT: 1. Spento: impostazione manuale di data ed ora da parte dell’utente.
TS6512HD 5 USB - Registrazione e riproduzione La porta USB frontale di questo ricevitore permette la lettura di file multimediali e la registrazione di programmi del digitale terrestre in chiaro. AVVERTENZE Il ricevitore è compatibile con dispositivi di memoria USB formattati con File System FAT32.
TELE System AVVERTENZE Prima di procedere alla prenotazione, assicurarsi che vi sia spazio sufficiente in memoria e, eventualmente, di disabilitare lo standby automatico (vedi par. 4.7). Ricordarsi di lasciare connesso il dispositivo di memoria USB. Gli orari di avvio di diversi timer non devono coincidere tra loro, considerare sempre almeno un minuto di differenza.
TS6512HD 7 Guida alla risoluzione dei problemi PROBLEMA POSSIBILI CAUSE COSA FARE ricevitore accende -L’interruttore generale -Commutare l’interruttore generale in (indicatore LED sul pannello frontale pannello posteriore è in posizione 0. posizione I per dare alimentazione. del ricevitore è totalmente spento) -La spina di alimentazione non è...
TELE System 8 Caratteristiche tecniche Tipo prodotto Ricevitore digitale terrestre (ETSI EN 300 744) per canali in chiaro con USB Frequenza in ingresso 147÷230 MHz (VHF) / 470÷862 MHz (UHF) Larghezza di banda di canale 6 / 7 / 8 MHz...
Page 15
Index Safety regulations ............................2 Product description and connections ......................3 Front Panel ............................3 Rear panel and connections ......................4 Remote Control Unit ......................... 5 2.3.1 Batteries ........................... 5 2.3.2 Buttons and related functions ....................5 First time installation ........................... 6 Receiver settings ............................
TELE System 1 Safety regulations We advise you to read the following advice concerning the safety regulations carefully in order to ensure safe use of the appliance. ELECTRICAL SUPPLY The appliance should only be supplied by a current of 230 Volt AC, 50Hz.
TS6512HD 2 Product description and connections 2.1 Front Panel 1. USB USB port for reading .JPG picture, .MP3 music, .MPEG2/MPEG4 video and for recording from digital terrestrial tuner source. CAUTION Admitted USB mass storage file systems: FAT32. It’s not guarantee the compatibility with all USB mass storage devices of the market.
TELE System 2.2 Rear panel and connections CAUTION It is good practice to connect the receiver with other appliances (e.g. TV, VCR, HI-FI, etc.) and the antenna before plugging in the mains lead. When the receiver is powered electrical voltage differences may be created when plugging in the jacks, which may generate currents that could damage the appliances.
TS6512HD 2.3 Remote Control Unit Get well acquainted with your remote control and you will find it much easier to navigate through the various menu options. 2.3.1 Batteries Information and warnings Battery type: 2 x AAA, 1.5V. Insert/replace the batteries at the first installation or when the remote control doesn’t work well.
TELE System 3 First time installation When all the connections on the receiver are ready (section 2.2), the mains lead is plugged in and the rear mains switch is on position I (ON), the receiver will start up automatically. If this does not happen, press the ON button on the front panel of the receiver or on the remote control.
TS6512HD 4 Receiver settings The first time installation procedure (chapter 3) will allow the receiver to be used with its basic functions. However the receiver offers many more advanced features and options that are illustrated in the following sections. 4.1 Password To access settings and events locked by the Parental Control (par.
TELE System 4.6 Software Upgrading Since your receiver is made to last, the time may come when its software needs to be modified or improved by updates. These updates will optimise the receiver’s functions or correct minor flaws. 4.6.1 Via USB When a software image file is made available, upload it on the root directory of an USB pendrive.
TS6512HD 5.1 TV program recording This receiver is equipped with a recording function, which allows the following actions: 1. Record a digital terrestrial program while watching a different channel in the same transmission frequency and using TimeShift (par. 5.2). 2. Record two different programs of the same transmission frequency and watch contemporarily another channel broadcasted on the same frequency of the recorded programs and use TimeShift (par.
TELE System 6 The menus The menu map: Main Menu Edit Channel Installation System Setup Tools Game PVR and Media Player -TV Channel List -Auto Scan -Language -Information -Othello -PVR Storage Information -Radio Channel List -Channel Scan -TV System -Factory Setting...
TS6512HD 7 Problem solver PROBLEM POSSIBLE CAUSE REMEDY 1. The receiver does not start (the -The main 0/I switch on back panel is -Change the switch position to I. LED display is not lighted up on the on position 0.
TELE System 8 Technical Specifications Product type Free to air digital terrestrial receiver (ETSI EN 300 744) with USB Input frequency range 147÷230 MHz (VHF) / 470÷862 MHz (UHF) Bandwidth 6 / 7 / 8 MHz Front Panel Display Menu language...
Page 27
Indeks Bezpiecze stwo ............................2 Opis produktu i poá cze ..........................3 Panel przedni ........................... 3 Panel tylni i poá czenia ........................4 Pilot zdalnego sterowania ........................ 5 2.3.1 Baterie ............................. 5 2.3.2 Funkcje pilota zdalnego sterowania ..................5 Pierwsze uruchomienie ..........................6 Ustawienia odbiornika ..........................
TELE System 1 Bezpiecze stwo W celu zapewnienia bezpiecze stwa korzystania z urz dzenia zaleca si zapoznanie i uwa ne przeczytanie poni szych uwag i informacji przed rozpocz ciem pierwszego uruchomienia. ZASILANIE Urz dzenie powinno byü zasilane pr dem 230 V AC, 50Hz.
TS6512HD 2 Opis produktu i poá cze 2.1 Panel przedni 1. USB Port USB do odczytu plików JPG ,MP3,MPEG2/MPEG4 i nagrywania. UWAGA Wymagany system plików: FAT32. Nie ma gwarancji kompatybilno ci wszystkich urz dze USB dost pnych na rynku z odbiornikiem.
TELE System 2.2 Panel tylni i poá czenia UWAGA Zaleca si podá czenie innych urz dze (np. TV, HI-FI, etc.) a tak e anteny przed podá czeniem odbiornika do zasilania. Gdy odbiornik podá czony jest do sieci ,podczas wá czania wtyczek wyst piü mog ró nice napi ü ,które mog uszkodziü...
TS6512HD 2.3 Pilot zdalnego sterowania Zapoznanie si z poni szymi informacjami uáatwi u ytkownikowi sprawne poruszanie si po MENU za pomoc pilota. 2.3.1 Baterie Informacje i ostrze enia Baterie: 2 x AAA, 1.5V. Umie ü/zamie baterie przy pierwszym uruchomieniu lub gdy pilot nie reaguje na funkcje.
TELE System 3 Pierwsze uruchomienie Je li wszystkie element zostaáy podá czone wraz z zasilaniem oraz wá cznik ustawiony jest na pozycje I(ON) odbiornik powinien uruchomiü si automatycznie. Je li tak si nie stanie naci nij przycisk ON na panelu odbiornika lub pilocie zdalnego sterowania.
TS6512HD 4 Ustawienia odbiornika Procedura pierwszego uruchomienie pozwoli na dost p do podstawowych funkcji odbiornika. Odbiornik oferuje wiele dodatkowych funkcji opisanych poni ej. 4.1 Hasáo Aby wej ü w opcje i ustawienia Kontroli rodzicielskiej (par. 4.2) nale y ustawiü hasáo; zostanie ono zdefiniowane przez u ytkownika ko cowego przy pierwszej instalacji (par.
TELE System 4.6 Aktualizacja oprogramowania Aktualizacja pozwoli na usprawnienie dziaáania systemu, co pozwoli na udoskonalenie m.in. funkcji odbiornika. 4.6.1 Przez USB Kiedy plik oprogramowania jest dost pny podá cz urz dzenie USB i wejd w menu Narz dzia - Aktualizacja...
TS6512HD 5.1 Nagrywanie programów TV Przed rozpocz ciem nagrywanie zweryfikuj status pami ci urz dzenia USB i dost pnego miejsca : wejd w menu PVR i Media Player - Informacje PVR . Konfiguracja nagrywania W menu PVR i Media Player - Ustawienia PVR menu, dost pne jest: Nagrywanie PS: specjalnie sformatowany plik dla nagranej zawarto ci(video-nagrywanie zawarto ci video,plików audio ) .jako alternatywa stosowane s...
TELE System 6 Menu Opis menu: Menu gáówne Edycja kanaáów Instalacja Ustawienia Narz dzia PVR i Media Player systemowe -Lista kanaáów TV -Auto skanowanie -J zyk -Informacje -Othello -Informacje PVR -Lista kanaáów -Skanowanie -System TV -Ustawienia fabryczne -Sudoku -Ustawienia PVR radiowych kanaáów...
TS6512HD 7 Rozwi zywanie problemów PROBLEM PRAWDOPODOBNA ROZWI ZANIE PRZYCZYNA 1. Odbiornik nie chce si uruchomiü -Przeá cznik gáówny na tylnym panelu -Zmie pozycji przeá cznika na I. (dioda LED nie wieci si na przednim 0/I jest na pozycji 0.
TELE System 8 Specyfikacje techniczne Typ produktu Odbiornik naziemnej TV cyfrowej (ETSI EN 300 744) z USB Zakres cz stotliwo ci wej ciowej 147÷230 MHz (VHF) / 470÷862 MHz (UHF) Szeroko ü kanaáów 6 / 7 / 8 MHz Wy wietlacz na przednim panelu...
Page 40
Free To Air, USB TELE System TS6512 HD Dichiarazione di conformità CE CE conformity declaration Tele System Electronic dichiara sotto la propria Tele System Electronic states that this product responsabilità che questo prodotto soddisfa i meets the basic European requirements of requisiti fondamentali delle direttive europee 2009/125/CE reg.
