TRAMONTANE MODEL
ACCORDING TO NF P 90 – 308 STANDARD
TO READ CAREFULLY AND TO KEEP FOR LATER REFERENCE
661, Rue J-B BIOT
Espace Polygone BP 4110
66000 PERPIGNAN
Tel : 00.33.4.68.61.03.45
E-mail :
contact@interpool-europe.com
COVER BAR
INSTALLATION MANUAL
Fax : 00.33.4.68.61.03.34
Serial N°:
Revision number : T-002-2009-01-23
1/14
Revision Number T-002-2009-01-23
ENGLISH
Advertisement
Table of Contents
Related Manuals for Astralpool TRAMONTANE
Summary of Contents for Astralpool TRAMONTANE
- Page 1 ENGLISH COVER BAR INSTALLATION MANUAL TRAMONTANE MODEL ACCORDING TO NF P 90 – 308 STANDARD TO READ CAREFULLY AND TO KEEP FOR LATER REFERENCE Serial N°: 661, Rue J-B BIOT Espace Polygone BP 4110 66000 PERPIGNAN Tel : 00.33.4.68.61.03.45 Fax : 00.33.4.68.61.03.34 E-mail : contact@interpool-europe.com...
-
Page 2: Table Of Contents
ENGLISH TABLE OF CONTENTS UNLOADING ......................2 DELIVERY ........................2 TOOLS REQUIRED FOR ASSEMBLY ............... 2 COMPONENTS OF THE COVER BAR ..............3 POSITIONING TO THE POOL ................... 4 CENTER THE COVER BAR TO THE POOL .............. 5 LOCATING AND DRILLING FOR IMPLEMENTATION FOR PITONS ....... 6 IMPLEMENTATION FOR STRAPS ................ -
Page 3: Unloading
ENGLISH UNLOADING Rectangular package ACCORDING TO THE DIMENSIONS OF THE COVER BAR 2 PERSONS FOR THE UNLOADING AND FOR THE INSTALLATION 10 min 1 HOUR UNLOADING INSTALLATION DELIVERY All our goods travel at the risks and the danger of the customer (Article, 100 of the commercial law). -
Page 4: Components Of The Cover Bar
ENGLISH COMPONENTS OF THE COVER BAR 1or 2 reducer’s handles According to the pool dimensions. 1 Key 6 faces (Allen) n°1.5 Tension pawls Pitons 1 bar cover 1 Installation manual OPTIONS Support with wheels Rolling handle 3/14 Revision Number T-002-2009-01-23... -
Page 5: Positioning To The Pool
ENGLISH POSITIONING TO THE POOL The positioning of the cover begins at stocking side of the pool. The stocking side is the side where the cover is totally rolled, or the opposite side at the stair, if stair is. For a good positioning of the cover, two persons are recommended. The first person stays in position at the stocking side, and keeps at the back’s cover. -
Page 6: Center The Cover Bar To The Pool
ENGLISH CENTER THE COVER BAR TO THE POOL The cover must be centred over the pool in relation to the width and the length. The tight fit X on the bellows diagram must be equal from part and the others of the pool, also for the tight fit β. -
Page 7: Locating And Drilling For Implementation For Pitons
ENGLISH LOCATING AND DRILLING FOR IMPLEMENTATION FOR PITONS One time the cover centred, spread all straps, and localized the good position of pitons and drilling with a concrete drill Ø 12mm about 50 cm the interior wall of the pool. STOCKING SIDE Pitons 50 cm... - Page 8 ENGLISH One time the cover entire fixing in the stocking side spread all the strap in an unrolling side and drilling with a concrete drill about 50 cm of the cover. UNROLLING SIDE 50 cm IMPORTANT The security conditions are straight at the ground and at the quality of pitons‘s fixation.
-
Page 9: Implementation For Straps
ENGLISH IMPLEMENTATION FOR STRAPS To position tension’s pawls on the piton take on before. This tension’s pawls will be used only, if the stocking side of the cover is fixed on his piton. For a good tightening, and a good manipulation of the tension’s strap, make like this. Take the strap in the tension’s pawls. -
Page 10: Utilisation
ENGLISH UTILISATION ROLLING UP: Release all the strap with the trigger of tension’s pawls and we open it in totally. The unrolling strap must be in the axel of the cover, it was unrolling totally without knot, nor rolling in ball. Take on the handle in the end tube unrolling side and rolling up the cover. -
Page 11: Imperative Recommandation
ENGLISH UNROLLING : Before the unrolling, you must control if the stocking side of the cover is spread at the pitons. You must be positioned at the end of the pool, and pull on the unrolling’s strap to covering totally on the pool. One time the pool is totally covering, take on all the strap in the tension’s pawls, and to clink like at the beginning at the installation. -
Page 12: Options: Assembly Of The Wheels System
ENGLISH OPTIONS: ASSEMBLY OF THE WHEELS SYSTEM The wheels will be used for rolling up the cover with even less effort. For assembly of the wheel’s system, you put the end of the tube in the shaft of the wheel’s system. To do like this in the other side Utilisation with wheel’s system for rolling up Take on the handle in the superior part of the wheel’s system. -
Page 13: Guarantees
ENGLISH GUARANTEES The cover guarantees is to 3 years. Tears, digs, colour or marks aren’t kept in guarantees. Are excluded hail storm damages, or a storm damages, and a no confirmed utilisation’s cover In case of fall of snow, the cover must be clear of snow. The water’s draining must be clean. -
Page 14: Security Councils
ENGLISH SECURITY COUNCILS WARNING : The swimming pool can constitute a big danger for your children. A drowning is very fast arrival. Children near a swimming pool demand your constant attentiveness and your active surveillance, even if they know how to swim. ... -
Page 15: Safety Certificate
ENGLISH SAFETY CERTIFICATE 14/14 Revision Number T-002-2009-01-23... - Page 16 ENGLISH NOTE 15/14 Revision Number T-002-2009-01-23...
