- Page 1 Under Cabinet Range Hood Range Hood QB series Installation Guide & Users Manual IMPORTANT: Read and save these instructions. NOTICE: Installer: Leave this guide with the homeowner Homeowner: Keep this guide for future reference...
- Page 3 This product is designed for indoor residential use only.
-
Page 7: Venting Requirements
Venting Requirements Height & Clearance • Vent system must terminate to the outside (roof or side wall). • DO NOT terminate the vent system in an at- tic or other enclosed area. • DO NOT use 4” (10.2 cm) laundry-type wall Cabinet or Single- caps. -
Page 8: Calculating Vent System Length
IMPORTANT: • A minimum of 8” round (standard for this range hood) or 3-1/4 x 10” rectangular duct (purchased separate- ly) must be used to maintain maximum airflow efficiency. • Always use rigid type metal/aluminum ducts if available to maximize airflow when connecting to provided duct. - Page 16 Use and Care Information : Operations: Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. Always leave safety grills and lters in place. Without these components, operating blowers could catch on to hair, ngers and loose clothing.
- Page 17 Measurements and Diagrams : All measurements in parenthesis are in millimeters. All inch measurements are converted from millimeters, thus inch measurements are estimated.
- Page 23 Replacing Filters: • Replace filters if they wear out due to age and prolonged use. Replacing the light bulb: 1 Remove baffle filter as per installation. 2 Make sure the hood is disconnected or close the circuit breaker. Reach into the range hood and disconnect power clip. 3 Reach into interior of range hood until touching both lateral clips located on the side of the puck light.
- Page 24 WARRANTY AND SERVICE For full warranty details on this product please visit: http://www.cosmoappliances.com/warranty TO RECEIVE WARRANTY SERVICE, YOUR PRODUCT MUST BE REGISTERED. TO REGISTER, VISIT: WWW.COSMOAPPLIANCES.COM/WARRANTY SCAN TO REGISTER...
- Page 25 REQUIRED FOR WARRANTY SERVICE IMPORTANT Ne pas Réexpédier ce Produit au Magasin Pour tout problème concernant ce produit, veuillez contacter le service des consommateurs Cosmo Customer Support au +1(888) 784-3108 UNE PREUVE D’ A CHAT DATEE EST REQUISE POUR BENEFICIER DE LA GARANTIE.
- Page 26 NOTE:...
- Page 28 Cosmo is constantly making efforts to improve the quality and performance of our products, so we may make changes to our appliances without updating this manual. Electronic version of this manual is available at: www.cosmoappliances.com...
