Congratulations!
You are installed in Bridging Mode. Your connection is "always on".
You have successfully installed your 3Com HomeConnect ADSL Modem Dual Link. The
Dual Link provides a
flexible mechanism
the Internet.
Your modem has the ability to support several ADSL service models. Your modem has
been installed to support the Bridging mode. In the Bridging mode your connection to
the Internet is always on. After modem installation, you configure your PCs as directed
by your Internet Service Provider. This typically means that you will configure the
TCP/IP protocol parameters on each local PC according to specific instructions from your
service provider.
To find out more about configuring additional PCs,
The modem installation procedure you have completed installed a program group on your
hard drive. This
program group
1.
Access the modem for
modem software. For the most part, you should not have to directly access your
modem.
2.
View this online guide.
3.
Install the
Instant Update
software updates for your modem over the Internet.
4.
Uninstall
the modem program group from your hard drive.
to link multiple computers to each other and to
provides shortcuts to:
diagnostics,
monitoring your connection and upgrading your
package which allows you to automatically obtain
click here.
