Installation and operating instructions for the
Heat Commander WOOD FURNACE
This manual is available for free download on the manufacturer's web site. It is a copyrighted
document. Re-sale is strictly prohibited. The manufacturer may update this manual from time
to time and cannot be responsible for problems, injuries, or damages arising out of the use
of information contained in any manual obtained from unauthorized sources.
Please keep this document!
READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLING
Printed in Canada
(
DF02003
AND OPERATING YOUR FURNACE.
model)
Verified and tested for Canada
and the United States
by an accredited laboratory
Stove Builder International Inc.
250, rue de Copenhague,
St-Augustin-de-Desmaures (Quebec)
Canada G3A 2H3
After-sale service: 418-908-8002
E-mail: tech@sbi-international.com
WRITE THE SERIAL NUMBER HERE :
45846A
22-09-2020
