PERFORMANCE SUMMARY

Table 1. Typical DC1505A Performance Summary (T
PARAMETER
Input Voltage
Output Voltage
Device Used and Difference

QUICK START PROCEDURE

Demonstration circuit description 1505A is easy to set
up to evaluate the performance of the LTC4360. Refer to
Figure 2 and Figure 3 for proper measurement equipment
setup and follow the procedure below.
1. Connect a power supply across V
2. Select protection type at JP1 and connect a voltmeter
across the corresponding output and GND:
a. For overvoltage protection select (A) OV and
connect to OUT(A). Figure 2a.
b. For overvoltage and negative voltage protection
select (B) OV/NV and connect to OUT(B).
Figure 2b.
2
= 25°C)
A
CONDITION
Protection (A) OV
Protection (B) OV/NV
Protection (C) OV/NV/RC
Input Range for Gate Turn-On
Protection (A) OV
Protection (B) OV/NV
Protection (C) OV/NV/RC
and GND.
IN
VALUE
0V to 30V
–30V to 30V
–30V to 30V
2.1V to 5.8V
LTC4360-1, ON Control
LTC4360-2, GATEP
LTC4360-2, GATEP
c. For overvoltage, negative voltage, and reverse
current protection select (C) OV/NV/RC, connect
to OUT(C). Figure 2c.
3. Select ENABLE at JP2 for protection (A) to enable.
4. For USB protection, connect a USB cable from J2 to
the USB device (Figure 3). Select the protection type
at JP1 and match JP3 to JP1. Connect a second USB
cable from a computer to J1.
