DEMO MANUAL DC1505A
QUICK START PROCEDURE
HOT
PLUG
USB CABLE
USB CABLE
PC
USB DEVICE
SELECT
SELECT USB PROTECTION
PROTECTION
(JP3 MUST MATCH JP1)
PROTECTION (A)
SELECT ENABLE
1505a FO3
Figure 3. DC1505A USB Protection Setup
dc1505af
5
