Quick Start Guide

Moving the EFW NIC to the New Device Set

Now that you have multiple device sets, you can move the EFW NIC from
the default device set to the No IP Initiation device set that you created in
the previous section by following the steps below.
1 In the Management Console, click the Device Sets tab in the
tree-view frame.
2 Click Default Device Set. This device set contains the EFW NIC that you
added earlier in this guide.
3 In the Device box, highlight the EFW device, and then click Move.
4 A list of alternative device sets appears. Select the Sample device set that
you created in the previous section, and click OK. You will see a feedback
window indicating that the new policy has been distributed to the
embedded firewall. The EFW device is moved to the new device set and
now enforces the new policy.

Testing Policy Enforcement and Viewing Audit Data

At this point you should have an EFW NIC enforcing the No IP Initiation policy.
To ensure that the policy is functioning as expected, the following steps
attempt to connect to the Internet by initiating the TCP protocol HTTP, which
should be denied by the policy being enforced. You will then view the audit
generated by the failed attempt.
1 On the machine hosting the EFW NIC, attempt to connect to
www.3com.com. If you were denied access to the site, the EFW NIC
is correctly enforcing the "No IP Initiation" policy. If you were able to
connect to the site, go back to the "Creating a Policy" section in this
guide and verify that you correctly set up the policy rules.
2 To view the audit generated by this access attempt using the Management
Console, follow the steps below:
a In the Audit menu, select Audit Browser (or click the
b In the Query menu, select New (or click the
window appears.
c Type All Recent Audit Records in the Query Name field.
d In the Rule tab, select the All Devices check box in the For area, and the
All rule matches check box in the Show area.
e In the Policy tab, select the All Policies check box in the For area, and
the All policy events check box in the Show area.
12
icon).
icon). The Query Editor
