- Page 1 Installation, Operation, and Maintenance Manual Model AF (42"/1200mm/54"/60"/66") LM/LMR Bearings...
-
Page 3: Table Of Contents
Table of Contents Table of Contents 1 Introduction and Safety ............................ 3 1.1 Introduction..............................3 1.2 Safety ................................ 3 1.3 Safety terminology and symbols ....................... 4 1.4 Environmental safety..........................5 1.5 User safety ..............................5 1.6 Precautions before work..........................6 1.7 Precautions during work.......................... - Page 4 Table of Contents 5.4 Shut down the pump ..........................44 5.5 Final Alignment............................44 6 Maintenance..............................45 6.1 Maintenance............................45 6.1.1 Preventative Maintenance......................45 6.1.2 Maintenance schedule ........................45 6.1.3 Bearing Maintenance ........................46 6.1.4 Shaft-seal maintenance ........................ 48 6.1.5 Packed Stuffing Box ........................49 6.1.6 Connection of Sealing Liquid ......................
-
Page 5: Introduction And Safety
Prohib- ited methods include any modification to the equipment or use of parts not provided by ITT. If there is any uncertainty regarding the appropriate use of the equipment, please contact an ITT representative before proceeding. -
Page 6: Safety Terminology And Symbols
Risk of injury and/or property damage. Operating a pump in an inappropriate application can cause over pressurization, overheating, and/or unstable operation. Do not change the service application without the approval of an authorized ITT representative. 1.3 Safety terminology and symbols... -
Page 7: Environmental Safety
WARNING: If the product has been contaminated in any way, such as from toxic chemicals or nuclear radi- ation, do NOT send the product to ITT until it has been properly decontaminated and advise ITT of these conditions before returning. -
Page 8: Precautions Before Work
1.6 Precautions before work • Helmet • Safety goggles, preferably with side shields • Protective shoes • Protective gloves • Gas mask • Hearing protection • First-aid kit • Safety devices Electrical connections Electrical connections must be made by certified electricians in compliance with all international, nation- al, state, and local regulations. -
Page 9: Safety Regulations For Ex-Approved Products In Potentially Explosive Atmospheres
ITT disclaims all responsibility for work done by untrained and unauthorized personnel. These are the personnel requirements for Ex-approved products in potentially explosive atmospheres: • All work on the product must be carried out by certified electricians and ITT-authorized mechan- ics. Special rules apply to installations in explosive atmospheres. •... -
Page 10: Product Approval Standards
Use of equipment unsuitable for the environment can pose risks of ignition and/or explosion. Ensure the pump driver and all other auxiliary components meet the required area classifica- tion at the site. If they are not compatible, do not operate the equipment and contact an ITT representative before proceeding. - Page 11 Economic losses Warranty claim ITT products are high-quality products with expected reliable operation and long life. However, should the need arise for a warranty claim, then contact your ITT representative. Model AF (42"/1200mm/54"/60"/66") LM/LMR Bearings Installation, Operation, and Maintenance Manual...
-
Page 12: Transportation And Storage
2 Transportation and Storage 2 Transportation and Storage 2.1 Inspect the delivery 2.1.1 Inspect the package Inspect the package for damaged or missing items upon delivery. Note any damaged or missing items on the receipt and freight bill. File a claim with the shipping company if anything is out of order. If the product has been picked up at a distributor, make a claim directly to the distributor. -
Page 13: Pump Storage Requirements
2.4 Uncrating / De-Skidding 2.3.1 Pump storage requirements Storage requirements depend on the amount of time that you store the unit. The normal packaging is designed only to protect the unit during shipping. Length of time in storage Storage requirements Upon receipt/short-term (less than six •... -
Page 14: Product Description
3 Product Description 3 Product Description 3.1 General This instruction manual is intended to assist those involved with the installation, operation and mainte- nance of Gould’s pumps. It is recommended that this manual be thoroughly reviewed prior to installing or performing any work on the pump or motor. -
Page 15: Nameplate Information
3.2 Nameplate information packing and (2) lantern rings to seal the shaft area. (2) flush ports are provided for lubrication. The inner- most flush port is used with process flow and the outermost port for water flush. A special alternate pack- ing arrangement is available that includes a throat bushing and additional ring of packing near the gland (see the attached addendum). - Page 16 3.2 Nameplate information Nameplate on the casing using English units Nameplate field Explanation Serial number of the pump MODEL Pump model SIZE Size of the pump STD. DIM. Standard ANSI dimensional code HYRO PRESS PSI Hydrostatic pressure at 100°F, in PSI FLOW Rated pump flow in GPM R.P.M.
- Page 17 3.2 Nameplate information Nameplate field Explanation MAT'L. Material of which the pump is constructed IMP. DIA. Impeller diameter, in inches CONT./ITEM NO. Customer contract or item number MAX. DIA. Maximum impeller diameter, in inches Model AF (42"/1200mm/54"/60"/66") LM/LMR Bearings Installation, Operation, and Maintenance Manual...
-
Page 18: Installation
4 Installation 4 Installation 4.1 Preinstallation AF units are usually shipped completely assembled. Check all bolts and nuts on the entire unit and make sure they are securely tightened. If necessary install and adjust drive components per manufacturer’s recommendations Equipment that will operate in a potentially explosive environment must be installed in accordance with the following instructions. -
Page 19: Sub-Base Leveling
4.1 Preinstallation Sleeve-type bolts Item Description Baseplate Shims Foundation Sleeve Bolt Figure 2: Sleeve type bolts J-type bolts Item Description Baseplate Shims or wedges Foundation Bolt Figure 3: J-type bolts 4.1.2 Sub-base Leveling Grouted Base When the unit is received with the pump and driver mounted to the sub-base, it should be placed on the foundation and the coupling halves or V-belts disconnected (see Figure titled Sub-base, top view). - Page 20 4.1 Preinstallation Figure 4: Sub-base, top view Figure 5: Sub-base, side view The sub-base should be supported on rectangular metal blocks or on metal wedges having a slight taper. There should be support blocks or wedges on both sides of each foundation bolt. A gap of about 19mm | 3/4"...
-
Page 21: Spring Mounted Base
4.1 Preinstallation Baseplate Shims or wedges Foundation Sleeve Bolt Figure 6: Build dam around foundation Pour grout through the grout holes in the sub-base, up to level of dam. Remove air bubbles from grout as it is poured by puddling, using a vibrator, or pumping the grout into place. Non-shrink grout is recommended. - Page 22 4.1 Preinstallation The following is a brief description of the spring pocket components and their function (see Figure: Spring pocket components). The adjusting screw is used to compress or relax the spring. Turning the screw causes the adjusting screw nut assembly to move vertically and change the amount of force the spring exerts against the spring retainer, which is fastened to the sub-base.
- Page 23 4.1 Preinstallation Place blocks under the sub-base, near each spring holder, and position the sub-base level on the blocks. A small gap (approx. 1.6 mm | 1/16") should exist between the flange of the vertical pipe and the pump elbow with the gasket in place (see Figure: Blocks placed under sub-base). Install several flange bolts to help maintain alignment of the flanges.
-
Page 24: Remove Spring From Spring Pocket
4.1 Preinstallation Check the alignment of the impeller and the pump elbow. If necessary, correct the alignment by ad- justing the springs or by using shims. NOTICE: If the flange gap is over 0.8 mm | 1/32", turn the adjusting screws a uniform amount to close the gap. -
Page 25: Connection Of Piping
4.2 Connection of Piping Grease fitting Spring holder (welded to sub-base) Adjusting screw Seal washer Jam nut 10. Grease seal Stop nut 11. Adjusting screw nut assembly Spring retainer 12. Lubricate with oil Bolts and nuts 13. Adjusting screw holder Spring Figure 11: Grease filled spring pocket assembly 4.2 Connection of Piping... - Page 26 4.2 Connection of Piping Piping runs should be as short as possible to minimize friction losses. DO NOT connect piping to the pump until the pump and driver hold-down bolts have been tight- ened. It is suggested that expansion loops or joints be properly installed in suction and /or discharge lines when handling liquids at elevated temperatures, so linear expansion of piping will not draw pump out of alignment.
-
Page 27: Pipe Hung Installation
4.3 Pipe Hung Installation valve prevents pump or seal damage due to reverse flow through the pump when the driver is turned off. Increasers, if used, should be placed between pump and check valves. Cushioning devices should be used to protect the pump from surges and water hammer if quick- closing valves are installed in system. -
Page 28: Drive Alignment Procedures
4.4 Drive Alignment Procedures After the grout has hardened, tighten the anchor bolt nuts. Check and correct the motor shaft alignment. We recommend the actual shaft misalignment for the flexible couplings be considera- bly less than the maximum allowed by the coupling manufacturer for long coupling life and re- duced vibration levels. -
Page 29: V-Belt Drive (Sheaves)
4.4 Drive Alignment Procedures NOTICE: Proper alignment is the responsibility of the installer and user of the unit. Trouble free operation can be accomplished by following these procedures. Initial Alignment (Cold Alignment) • Before Grouting Sub-base - To ensure alignment can be attained. After Grouting Sub-base - To ensure no changes have occurred during the mounting process. - Page 30 4.4 Drive Alignment Procedures Check Belt Fit - Regardless of the belt section used, the belt should never be allowed to bottom in the groove. This will cause the belts to lose their wedging action and slippage can occur. Sheaves or belts that permit such a condition to occur should be changed. Maintain Proper Belt Tension - Proper tension is essential for long belt life.
-
Page 31: Gear Drive (Couplings)
4.4 Drive Alignment Procedures If any questions arise pertaining to the drive limitations, consult the manufacturer. 4.4.2 Gear Drive (Couplings) NOTICE: The coupling used in an ATEX classified environment must be properly certified. Remove the guard or guards by referring to the assembly/disassembly instructions. Disconnect motor/ gearbox and the pump/gearbox coupling halves before proceeding with the alignment. - Page 32 4.4 Drive Alignment Procedures Alignment Procedure On gear driven AF pumps angular and parallel misalignment are corrected in the vertical direction by means of shims under the motor or gearbox mounting feet, and in the horizontal direction by adjusting bolts that slide the motor or gearbox in the proper direction. After each adjustment, it is necessary to recheck the alignment of the coupling halves.
- Page 33 4.4 Drive Alignment Procedures Record the largest gauge size that fits snugly between the two flanges. Rotate both flanges to position 3 - 180° Insert a feeler gauge at the periphery of the couplings at position 3. Record the largest gauge size that fits snugly between the two flanges. Calculate the difference between the readings at positions 1 and 3.
-
Page 34: Impeller Alignment
4.5 Impeller Alignment NOTICE: Care must be taken to have the straight edge parallel to the axis of the shafts Complete Alignment A unit is in complete alignment when both indicators "A" (angular) and "P" (parallel) do not vary by more than 0.076mm | 0.003"... - Page 35 4.5 Impeller Alignment Turn the shaft by hand, if the impeller rubs the inside of the casing it must be realigned. The following steps are used to align the impeller. NOTICE: Impeller rubbing is often caused by pipe strain or belt tension. Pipe strain must be eliminated prior to impeller alignment.
-
Page 36: Impeller Alignment Worksheet
4.6 Impeller alignment worksheet 4.6 Impeller alignment worksheet 4.7 Rotation Check Before the V-belts or couplings are installed, the motor should be wired and the direction of rotation checked. A rotation arrow is located on the bearing housing (134C). Serious damage could occur if the pump is run the wrong direction. Model AF (42"/1200mm/54"/60"/66") LM/LMR Bearings Installation, Operation, and Maintenance Manual... -
Page 37: Installation And Operation Checklist
4.8 Installation and Operation Checklist NOTICE: When installing in a potentially explosive environment, ensure that the motor is properly cer- tified. 4.8 Installation and Operation Checklist Table 5: Installation and Operation Checklist Complete Initial Description Reference Manual read and understood AF 42"-66"... -
Page 38: Commissioning, Startup, Operation, And Shutdown
5 Commissioning, Startup, Operation, and Shutdown 5 Commissioning, Startup, Operation, and Shutdown 5.1 Preparation for start-up NOTICE: When installing in a potentially explosive environment, ensure that the motor is properly cer- tified. Damage occurs from: Checking rotation Increased vibration levels-affects bearings, stuffing box or seal chamber and mechanical seal Increased radial loads Stresses on shaft and bearings Heat build up-Vaporization causing rotating parts to score or seize Cavitation-Damage to internal surfaces of pump... - Page 39 5.1 Preparation for start-up V-Belt Lock out power to the driver. Remove the V-belt guard. Make sure the sheaves are securely fastened to shafts. Unlock driver power. Make sure everyone is clear. Jog the driver just long enough to determine direction of rotation. Rotation must correspond to an arrow on bearing housing.
- Page 40 5.1 Preparation for start-up An oil with a higher viscosity than required will increase the bearing operating temperature because of the extra viscous drag, but never to the point where the viscosity becomes lower than required from the increased heat generation. It is therefore better for the bearings to have an oil that is too heavy rather than too light.
- Page 41 5.1 Preparation for start-up Packed stuffing box The original equipment packing is a suitable grade for the service intended. To pack the standard stuffing box use the following procedure: For the special (6) ring packing arrangement see Bearing alignmentThe bearing alignment collar is used to install the radial bearing on the 4MXR, 5MXR, and 6MXR bearing configurations.
-
Page 42: Start The Pump
5.2 Start the Pump Leakage Normal leakage for a properly adjusted box, depending on shaft size and speed, varies from a few drops a second to a small trickle out of the gland. Mechanical seal The mechanical seal used in an ATEX classified environment must be properly certified. The mechanical seal must always be properly flushed. - Page 43 5.2 Start the Pump WARNING: If pump becomes plugged, shut down pump and unplug prior to restarting. CAUTION: Foreign objects in the pumped liquid or piping system can block the flow and cause ex- cess heat generation, sparks and premature failure. Make sure that the pump and sys- tems are free of foreign objects before and during operation.
-
Page 44: Operation
5.3 Operation CAUTION: Risk of equipment damage due to dry operation. Immediately observe the pressure gauges. If discharge pressure is not quickly attained, stop the driver immediately, reprime, and attempt to restart the pump. Set desired flow If your system is equipped with a variable frequency drive (VFD) or a variable speed V-belt drive, you may at this point want to set your speed for the desired flow. - Page 45 5.3 Operation While field conditions preclude absolute accuracy, a check of pump performance will give reason- ably close results. This can be done by installing a mercury manometer at pipe taps located at least-one pipe diameter away from the suction and discharge flanges of the pump. If-gauges are used, the pressure differential times 2.31 divided by the specific gravity of the slurry indicates the TDH against which the pump is actually operating.
-
Page 46: Shut Down The Pump
5.4 Shut down the pump High HP demand Increased head or viscosity Pump speed too high Specific-gravity of slurry higher-than normal Packing gland pulled up too tight Impeller rubbing in casing Noisy or rough operation Throttled suction or plugging Impeller rubbing in casing Damage occurs from: Increased vibration levels - Affects bearings, stuffing box seal chamber, and mechanical seals. -
Page 47: Maintenance
• Motor load readings • PumpSmart control system For assistance in selecting the proper instrumentation and its use, please contact your ITT/Goulds repre- sentative. 6.1.2 Maintenance schedule NOTICE: The preventive maintenance section must be adhered to in order to keep the applicable ATEX classification of the equipment. -
Page 48: Bearing Maintenance
6.1 Maintenance Routine maintenance Perform these tasks whenever you perform routine maintenance: • Lubricate the bearings. • Inspect the seal. • Perform a vibration analysis. • Monitor the discharge pressure. • Monitor the temperature. Routine inspections Perform these tasks whenever you check the pump during routine inspections: •... - Page 49 ATEX certified and the listed temperature exceeds the applicable value shown in the table under ATEX identification, then that temperature is not valid. Should this situation occur, please consult with your ITT/Goulds representative. For ATEX applications bearing replacement (all) is recommended after 50,000 hours of operation.
-
Page 50: Shaft-Seal Maintenance
Cartridge seals installed by the user require disengagement of the hold- ing clips prior to operation, allowing the seal to slide into place. If the seal has been installed in the pump by ITT, these clips have already been disengaged. Other mechanical seal types For other types of mechanical seals, refer to the instructions provided by the seal manufacturer for instal- lation and setting. -
Page 51: Packed Stuffing Box
6.1 Maintenance Mechanical seal life The life of a mechanical seal depends on the cleanliness of the pumped fluid. Due to the diversity of op- erating conditions, it is not possible to give definite indications as to the life of a mechanical seal. 6.1.4.2 Packed stuffing-box maintenance WARNING: •... - Page 52 6.1 Maintenance Correct Incorrect Figure 17: Packing rings Insert the lantern ring with tapped extractor holes facing outward from the box, be sure it is aligned with the flush ports in the stuffing box. Model AF (42"/1200mm/54"/60"/66") LM/LMR Bearings Installation, Operation, and Maintenance Manual...
-
Page 53: Connection Of Sealing Liquid
6.1 Maintenance Figure 18: Insert lantern ring 12. Install the gland nuts finger tight. Then with the lubricating supply on and the pump running, gradu- ally tighten the gland nuts one flat at a time, while observing the leakage and stuffing box tempera- ture. -
Page 54: Labyrinth Seals
6.2 Disassembly 6.1.7 Labyrinth Seals Labyrinth seals are found on the inboard and outboard end caps of the bearing housing to prevent con- taminants from entering the bearing housing. On some older models lip seals were used. These were assisted by cast slingers that fling contaminant fluids away prior to reaching the lip seals. -
Page 55: Disassemble The Pump
6.2 Disassembly Item Description Coupling guard half Annular groove Pump end plate Driver 6.2.2 Disassemble the Pump Refer to the 8.2 AF Parts List 42-54 inch Pumps on page 8.4 AF Parts List 60-66 inch End Suction Pumps on page 8.3 AF Parts List 60-66 inch Top Suction Pumps on page 69,8.2.3 42-54 AF with LMR Bearings / Mechanical Seal / and Casing Gasket Seal on page 8.2.4 42-54 with LM Bearings /... -
Page 56: Disassemble The Power End
6.2 Disassembly Support bearing housing (134) and impeller end of shaft (122). Remove hex head bolts (370G) that secure bearing housing (134) to suction elbow (315A). If packing is used, disassemble the gland (107), packing (106), and lantern rings (105) from stuffing box. -
Page 57: Reassembly
6.3 Reassembly 6.3 Reassembly 6.3.1 Reassemble the Pump Be sure shaft (122) and sleeve (126) are clean and free of all burrs. Slide shaft sleeve (126) over shaft (122), making sure that O-rings are in place as indicated on assembly drawing. Secure sleeve with set screw (222C) and key (128D). -
Page 58: Reassemble The Drive / Guard
6.3 Reassembly Install (6) thrust bearings springs (9890) in thrust bearing retainer (109) or bearing housing (134) halves. Use thick grease in each hole to help hold springs until assembly. Lower shaft (122) into bottom half of bearing housing (134). Be careful not to damage bearings or machined fits. - Page 59 6.3 Reassembly 500A 500A Figure 21: Pump to sub-base reassembly Install V-belts and re-apply tension by adjusting the slide base away from the pump. Adjust and check the tension per the drive manufacturers instructions. Install belts Shift slide base Figure 22: V-belt installation Fasten the guard base (501) to the sub-base using screws (502).
- Page 60 6.3 Reassembly Figure 23: Guard base to sub-base reassembly Check impeller alignment and re-align if necessary according to instructions for (impeller align- ment). Direct connect configuration 10. Using a crane, lift the pump into place on the sub-base. Be careful not to damage the pump by striking any beams or walls that may be near the pump. If any shims were found under the bearing housing feet during disassembly replace them at this time.
-
Page 61: Inspections
6.3 Reassembly Figure 26: Coupling guard reassembly 17. Check impeller alignment and re-align if necessary according to instructions impeller alignment. 18. Fill pump with proper lubricant. Refer to preventative maintenance for requirements. 19. Connect all auxiliary piping and tubing 20. Fill system piping so pump impeller is submerged, flush the pump if necessary. 21. - Page 62 6.3 Reassembly Bearings The bearings (112, 112C, and 168C) should be inspected for contamination and damage. The condition of the bearing will provide useful information on operating conditions in the bearing housing. Lubrication condition and residue should be noted. Bearing damage should be investigated to determine the cause. If cause is not normal wear, it should be corrected before the pump is returned to service.
-
Page 63: Troubleshooting
7 Troubleshooting 7 Troubleshooting 7.1 Pump Troubleshooting Table 8: Pump Troubleshooting Symptom Cause Remedy Pump not primed or prime lost, liquid Fill system piping completely so the level does not completely fill elbow impeller is submerged Suction inlet clogged Remove obstructions from pump inlet Impeller clogged with foreign material Back flush pump or manually clean impeller Suction and /or discharge valve... - Page 64 7.1 Pump Troubleshooting Symptom Cause Remedy Pump assembled incorrectly Compare pump assembly to instruc- tion manual Higher solids concentration than Analyze pumpage and correct or specified change pump wet end materials to harder composition Excessive leakage from stuffing box Packing gland improperly adjusted Tighten gland nuts Stuffing box improperly packed Check packing and re-pack box...
- Page 65 7.1 Pump Troubleshooting Symptom Cause Remedy Piping not properly anchored Check to see if excessive pipe strain is being transferred to pump flanges Pump and/or driver not secured to Check fasteners, if loose check align- sub-base ment and re-tighten Specific gravity higher than specified Analyze pumpage and compare to specified gravity Viscosity higher than specified Analyze pumpage and compare to...
- Page 66 7.1 Pump Troubleshooting Symptom Cause Remedy Suction pressure too high Check liquid levels and static suction pressure Bearing installed incorrectly Check bearing orientation to sectional drawing Impeller out of balance Check pump vibrations, if necessary rebalance impeller Overheating of seal faces Check flush flow with mfgr’s recom- mendation, increase if necessary Excessive shaft deflection...
-
Page 67: Spare Parts
8 Spare parts 8 Spare parts Recommended spare parts In order to prevent a long and costly downtime period, especially on critical services, it is advisable that you have these spare parts on hand: 8.1 Spare Parts When ordering spare parts, always state Goulds Serial No., and indicate part name and item number from relevant sectional drawing. -
Page 68: Top Suction) Af With Lmr Bearings
8.2 AF Parts List 42-54 inch Pumps Item Part Description Item Part Description Part of 134 NUT,HEX 1"- 8 HVY 370I NUT, HEX, BEARING FRAME TO ELBOW assy Part of 134 PIN,TAPER #10 X 3-1/2" (PLN) LOCKWASHER, THRUST BEARING assy LOCKNUT, THRUST BEARING KEY, COUPLING 168C... -
Page 69: Af With Lmr Bearings / Mechanical Seal / And Casing Gasket Seal
8.2 AF Parts List 42-54 inch Pumps 8.2.3 42-54 AF with LMR Bearings / Mechanical Seal / and Casing Gasket Seal Refer to 8.2 AF Parts List 42-54 inch Pumps on page 65 Model AF (42"/1200mm/54"/60"/66") LM/LMR Bearings Installation, Operation, and Maintenance Manual... -
Page 70: With Lm Bearings / Special Packing Arrangement / Dual Casing O-Ring Seal
8.2 AF Parts List 42-54 inch Pumps 8.2.4 42-54 with LM Bearings / Special Packing Arrangement / Dual Casing O-Ring Seal Refer to 8.2 AF Parts List 42-54 inch Pumps on page 65 Model AF (42"/1200mm/54"/60"/66") LM/LMR Bearings Installation, Operation, and Maintenance Manual... -
Page 71: Af Parts List 60-66 Inch Top Suction Pumps
8.3 AF Parts List 60-66 inch Top Suction Pumps 8.3 AF Parts List 60-66 inch Top Suction Pumps Item Part Description Item Part Description CASING 357D HEX NUT, ELBOW TO CASING Model AF (42"/1200mm/54"/60"/66") LM/LMR Bearings Installation, Operation, and Maintenance Manual... -
Page 72: Top Suction) Af With Lmr Bearings
8.3 AF Parts List 60-66 inch Top Suction Pumps Item Part Description Item Part Description PROPELLER 358U PIPE PLUG [1/2-14 NPT] (NOT SHOWN) LANTERN RING 358V PIPE PLUG [1"-11.5 NPT] (NOT SHOWN) PACKING, PACKED BOX 360R GASKET, BRG., INBOARD GLAND 360X GASKET, BRG., OUTBOARD RETAINER, THRUST BEARING... -
Page 73: Af With Lmr Bearings / Mechanical Seal And Casing Gasket Seal
8.3 AF Parts List 60-66 inch Top Suction Pumps 8.3.2 60-66 AF with LMR Bearings / Mechanical Seal and Casing Gasket Seal Refer to 8.3 AF Parts List 60-66 inch Top Suction Pumps on page 69 Model AF (42"/1200mm/54"/60"/66") LM/LMR Bearings Installation, Operation, and Maintenance Manual... -
Page 74: Af Parts List 60-66 Inch End Suction Pumps
8.4 AF Parts List 60-66 inch End Suction Pumps 8.4 AF Parts List 60-66 inch End Suction Pumps Item Part Description Item Part Description CASING 357D HEX NUT, ELBOW TO CASING PROPELLER 358U PIPE PLUG [1/2-14 NPT] (NOT SHOWN) LANTERN RING 358V PIPE PLUG [1"-11.5 NPT] (NOT SHOWN) PACKING, PACKED BOX... -
Page 75: End Suction) Af With Lm Bearings
8.4 AF Parts List 60-66 inch End Suction Pumps Item Part Description Item Part Description 128D SLEEVE KEY 370H CAP SCREW, THRUST RETAINER TO BEARING FRAME BEARING FRAME ASSEMBLY 370I HEX NUT, BEARING FRAME TO ELBOW LOCKNUT, THRUST BEARING LOCKNUT CLIP 168C BEARING, RADIAL INBOARD MECHANICAL SEAL... -
Page 76: Af With Lm Bearings / Special Packing Arrangement / Dual Casing O-Ring Seal
8.4 AF Parts List 60-66 inch End Suction Pumps 8.4.2 60-66 AF with LM Bearings / Special Packing Arrangement / Dual Casing O-Ring Seal Refer to 8.4 AF Parts List 60-66 inch End Suction Pumps on page 72 Model AF (42"/1200mm/54"/60"/66") LM/LMR Bearings Installation, Operation, and Maintenance Manual... - Page 77 8.4 AF Parts List 60-66 inch End Suction Pumps Model AF (42"/1200mm/54"/60"/66") LM/LMR Bearings Installation, Operation, and Maintenance Manual...
-
Page 78: Special Packing Arrangement
9 Appendix I 9 Appendix I 9.1 Special Packing Arrangement (High pressure, dual flush packing) The following information covers the installation, operation and maintenance of the high pressure, dual flush packing arrangement. This arrangement was developed for high pressure, to minimize product dilu- tion, and to minimize external packing leakage. - Page 79 9.1 Special Packing Arrangement The flush pressures should be 10% higher than the pressure inside the pump. For end suction pumps this will also include pump discharge pressure. Product flush pressure to the inner lantern ring may be slightly less than the water flush pressure to ensure flow toward the inside of the pump. The flush flow depends on the application, the more heat generated the higher the flows must be to ef- fectively remove the heat.
- Page 80 9.1 Special Packing Arrangement Correct Incorrect Figure 29: Packing Rings Expand the first coil as shown and insert into stuffing box. Tamp the packing up against the re- strictor bushing shoulder firmly with a nylon bar or wood rod. Note, where the cut is positioned. Assemble the first lantern ring around the shaft and push it squarely into the stuffing box until it bottoms out against the first ring of packing.
- Page 81 ITT Goulds Pumps, Inc. 240 Fall Street Seneca Falls, NY 13148 Form IOM.AF.42-66.en-US.2020-02 ©2020 ITT Inc. The original instruction is in English. All non-English instructions are translations of the original instruction.
