TE Connectivity MQS 3-1579014-9 Operating Instructions Manual

Hand tool
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operating Instructions
MQS Hand Tool 0.13–0.17 mm²
PN: 4-1579014-3
Operating Instructions No.:
Operating Instructions, PN
Language:
411-18600 Rev. A
4-744017-0
en (Translation of the German original version)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MQS 3-1579014-9 and is the answer not in the manual?

Questions and answers

Related Manuals for TE Connectivity MQS 3-1579014-9

Summary of Contents for TE Connectivity MQS 3-1579014-9

  • Page 1 Operating Instructions MQS Hand Tool 0.13–0.17 mm² PN: 4-1579014-3 Operating Instructions No.: 411-18600 Rev. A Operating Instructions, PN 4-744017-0 Language: en (Translation of the German original version)
  • Page 2 It should be noted that our products are subject to natural wear and age- ing processes. © TE Connectivity Ltd. All right reserved, including applications for industrial property rights. We reserve all rights of disposal such as copying and transfer rights.

  • Page 3: Table Of Contents

    MQS Hand Tool 0.13–0.17 mm² General Specifications ....................3 Copyrights, industrial property rights...................... 3 Using these Operating Instructions................3 Abbreviations used ..........................4 General Safety Instructions ..................4 Intended Use ............................5 Improper use ............................5 Reasonably foreseeable misuse ......................5 Warnings in these instructions .......................

  • Page 4: General Specifications

    Read the instructions in full, particularly Section 3, "General Safety Instructions", before working with the hand tool. TE Connectivity Ltd. accepts no liability for any loss or damage attributed to failure to follow the op- erating instructions. These operating instructions must be supplemented by the hand tool user with instructions based on existing national regulations for the prevention of accidents and environmental protection.

  • Page 5: Abbreviations Used

    2.1 Abbreviations used Abbrevia- Meaning Micro Quadlock System Part number RoHS Restriction of (the use of certain) hazardous substances Restriction (of the use of certain) hazardous substances 3 General Safety Instructions The hand tool has been manufactured in accordance with the generally accepted codes of practice. Nonethe- less, there is a risk of personal injury and material damage if the following general safety instructions and the warnings preceding the individual operating instructions are not followed.

  • Page 6: Intended Use

    Cumulative trauma complaints may result from prolonged use of hand tools. TE Connectiv- ity hand tools are intended for occasional use with low part counts. TE Connectivity offers a wide selection of tools to meet increased demand or for production.

  • Page 7: While Working With The Hand Tool

    Dispose of the tool in compliance with the environmental rules described in Section 9, "Disposal". 3.5 User obligations The user of the hand tool from TE Connectivity Ltd. must train their personnel on the following matters: Following and using the operating instructions and observing statutory provisions.

  • Page 8: Scope Of Delivery

    4 Scope of Delivery The scope of delivery comprises the following: 1 Hand tool, TE PN 3-1579014-9 1 Operating Instructions 411-18600, TE PN 4-744017-0 5 Terminals to be processed The following MQS terminals can be processed with the hand tool: Terminal Terminal PN TE processing specification...

  • Page 9: Hand Tool Description

    6 Hand tool description The hand tool essentially consists of a crimping head, two handles, a ratchet mechanism, a crimping die, a hinged terminal holder and a hinged wire stop. The crimping die contains two crimp nests suitable for the en- tire cross-section range of the terminals to be processed.

  • Page 10: Crimping Procedure

    7 Crimping procedure Based on the wire cross-section and the relevant processing specification, determine the right crimping die for the terminal to be processed. Proceed as follows to crimp the terminal: Close the handles until the ratchet of the ratchet mechanism releases and allows you to fully open the handles.
  • Page 11 Fig. 5: Push the terminal against the stop in the holder Fig. 6: Secure the terminal in place Close the terminal holder. The terminal is now held in the crimping die. Insert the wire with seal, stripped according to the processing specification, into the crimp barrel of the terminal until it reaches the wire stop.
  • Page 12 Hold the wire against the stop and press the handles together until the ratchet mechanism releases. Let the crimping tool open fully. Note: Stop pressing the handles of the hand tool when the ratchet mechanism releases. You will hear a dis- tinct click.

  • Page 13: Maintenance And Servicing

    For environmentally sound disposal, return the hand tool and its components to the address stated in Section 10.1, "Customer support address". 10 Appendix 10.1 Customer support address TE Connectivity c/o Schenck Technologie- und Industriepark GmbH Landwehrstr. 55 / Gebäude 83 64293 Darmstadt Field Service EMEA@te.com...
