Appendix B: Wall Outlet Dimensions
Appendix B: Wall Outlet Dimensions
Make sure the wall or cubicle opening where the NJ90 is being
installed complies with the NEMA-WD6 standard, as described
below.
1.750"
(44.45 mm)
3.28125"
2.8125"
(83.31 mm)
(71.44 mm)
reference
Screw holes
Figure 4 - Wall Outlet (NEMA-WD6) Dimensions
