Moog MATRIARCH Firmware Update page 5

V1.2.0 RELEASE NOTES
(Continued)
Global Parameters
Default Group (Group 0)
0.8 Noise Filter Cutoff
Matriarch uses a 1-pole high-pass filter (VCF) to control the tonality and coloration of the analog Noise generator. Low-end content is
removed as the filter cutoff frequency is increased. Use any of the white keys to set the cutoff frequency of the Noise Filter, from
lowest (C0) to highest (C4). The Default is the lowest setting (C0).
0.9 Delay Filter Brightness
The output of the Stereo Delay can be set to either a Bright tone or a Dark tone.
Use the lowest two white keys to select Dark (C0), or Bright (D0). The Default is Bright (D0).
0.10 Delay Sync CV Bend
The Delay Sync CV Bend parameter sets the behavior of the TIME CV inputs when the Delay is synchronized to internal or
external clock. With Delay CV Sync Bend On, the TIME CV inputs "bend" the Delay Time relative to its currently synchronized
tempo, up to plus-or-minus 33%. This can be useful for adding choral motion or warble to synchronized Delay effects. With
Delay CV Sync Bend Off, the TIME CV inputs work identically to the front-panel TIME and SPACING knobs, selecting tempo-
synced clock divisions of the of the currently synchronized tempo. Use the lowest two white keys to select OFF (C0), or ON
(D0). The Default is OFF.
Global Parameters
1.1 MIDI Input Channel
Matriarch can send and receive data on any MIDI Channel, from 1 to 16. Use the first 16 white keys (C0 to D2) to select the
corresponding MIDI Input Channel (1 to 16).
1.2 MIDI Output Channel
Matriarch can send and receive data on any MIDI Channel, from 1 to 16. Use the first 16 white keys (C0 to D2) to select the
corresponding MIDI output channel (1 to 16).
1.3 MIDI Echo (USB)
MIDI Echo USB allows MIDI data received at the USB MIDI input to be re-transmitted via the USB MIDI output,
the DIN MIDI output, or both. Use the first four white keys to select OFF (C0), DIN OUTPUT (D0), USB OUTPUT (E0), or DIN &
USB OUTPUTS (F0). The default is OFF (C0).
1.4 MIDI Echo (DIN)
MIDI Echo DIN allows MIDI data received at the DIN MIDI input to be re-transmitted via the DIN MIDI output, the USB MIDI
output, or both. Use the first four white keys to select OFF (C0), DIN OUTPUT (D0), USB OUTPUT (E0), or DIN & USB OUTPUTS
(F0). The default is OFF (C0).
Group 1
Group Select Parameter
Key Select Key
(none)
(none)
(none)
Group Select Parameter
Key Select Key
C#2
C#2
C#2
C#2
Sync Enable
Button Blinks
F#1 8 x
G#1 9 x
A#1 10 x
Sync Enable
Button Blinks
C#0 1 x / 1 x
D#0 1 x / 2 x
F#0 1 x / 3 x
G#0 1 x / 4 x
