Global Settings; Here's How It Works - Moog MATRIARCH Firmware Update

V1.2.0 RELEASE NOTES

GLOBAL SETTINGS

Most Matriarch front-panel controls relate to creating sound. Below the surface, there is another level of parameters
known as the Global Settings, which determine how the instrument operates, and how
it can connect and interact with other electronic instruments and audio equipment.
To access Matriarch's Global Settings, simultaneously press and hold the HOLD [SHIFT] button
located in the Left-Hand Controller and the SYNC ENABLE button located in Oscillator 1 until the
SYNC ENABLE button begins to blink. This indicates that Matriarch is in the Global Settings edit mode. Now you can
use the keyboard commands listed below to make any needed changes to the Global Settings. The SYNC ENABLE
button will blink a specific number of times to indicate which Global Setting is currently selected. When you have
finished making any changes, simply press the SYNC ENABLE button to exit the Global Settings edit mode.
Once you are in the Global Settings edit mode, you can freely select different groups and parameters using the black
keys, and can switch the value of the selected parameters by using the white keys, until you press the SYNC ENABLE
button to exit. Double-tapping on a white key will both update the setting and exit the Global Settings edit mode
simultaneously.
NOTE: Global Settings are retained even when the power has been turned off.
C#0 C#1 C#2 C#3
D#0 F#0 G#0 A#0 D#1 F#1 G#1 A#1 D#2 F#2 G#2 A#2 D#3 F#3 G#3 A#3
C0 C1 C2 C3 C4
D0 E0 F0 G0 A0 B0 D1 E1 F1 G1 A1 B1 D2 E2 F2 G2 A2 B2 D3 E3 F3 G3 A3 B3

HERE'S HOW IT WORKS:

Global Settings are organized in groups of ten. An individual parameter in the chosen group is selected using one of
the lower 10 black keys, starting with C#0. The white keys, starting with C0, are used to set the value of the chosen
parameter. The first 10 parameters are in the default group, and no group selection is required. Additional groups are
selected using one of the upper black keys, starting with C#2. To access these additional parameters, hold down the
Group Select key while pressing the individual Parameter Select key.
