Moog MATRIARCH Firmware Update page 9

V1.2.0 RELEASE NOTES
(Continued)
Global Parameters
3.2 Clock Output PPQN
In order for an external device to sync correctly to the Matriarch Sequencer and Arpeggiator, this Global Setting allows you to
specify how many pulses are sent per quarter note (PPQN). Use the first fourteen white keys to choose the number of clock
pulses sent per quarter note. (C0) = 1 PPQN; (D0) = 2 PPQN; (E0) = 3 PPQN; (F0) = 4 PPQN; (G0) = 5 PPQN; (A0) = 6 PPQN;
(B0) = 7 PPQN; (C1) = 8 PPQN; (D1) = 9 PPQN; (E1) = 10 PPQN; (F1) = 11 PPQN; (G1) = 12 PPQN; (A1) = 24 PPQN; (B1) = 48 PPQN.
The Default is 4 PPQN (sixteenth note clock).
3.3 KB CV OUT Range
The Matriarch keyboard generates a specific control voltage for every note played. The voltage range of this signal appears
at the KB CV OUT jack on the Matriarch rear panel, and can be set to (-5V to +5V) or (0V to +10V) in order to accommodate
another synthesizer or piece of electronic music gear. Use the first two white keys to select either -5V to +5V (C0), or 0V to +10V
(D0). The Default is -5V to +5V.
3.4 Arp/Seq CV OUT Range
The Matriarch Arpeggiator and Sequencer generate a specific control voltage for every note played. The voltage range of this
signal appears at the CV OUT jack in the ARP / SEQ module on the front panel, and can be set to (-5V to +5V) or (0V to +10V) in
order to accommodate another synthesizer or piece of electronic music gear. Use the first two white keys to select either -5V to
+5V (C0), or 0V to +10V (D0). The Default is
-5V to +5V.
3.5 KB VEL OUT Range
The Matriarch keyboard generates a specific control voltage based on the dynamics of every note played. The voltage range
of this signal appears at the KB VEL OUT jack on the rear panel, and can be set to (0V to +5V) or (0V to +10V) in order to
accommodate another synthesizer or piece of electronic music gear. Use the first two white keys to select either 0V to +5V (C0),
or 0V to +10V (D0). The Default is 0V to +5V.
3.6 Arp/Seq VEL OUT Range
The Matriarch Arpeggiator and Sequencer generate a specific control voltage based on the dynamics of every note played. The
voltage range of this signal appears at the VEL OUT jack in the ARP / SEQ module on the front panel, and can be set to (0V to
+5V) or (0V to +10V) in order to accommodate another synthesizer or piece of electronic music gear. Use the first two white
keys to select either 0V to +5V (C0), or 0V to +10V (D0). The Default is 0V to +5V.
3.7 KB AT OUT Range
The Matriarch keyboard generates a specific control voltage based on the amount of Aftertouch being applied. The voltage
range of this signal appears at the KB AT OUT jack on the rear panel, and can be set to (0V to +5V) or (0V to +10V) in order to
accommodate another synthesizer or piece of electronic music gear. Use the first two white keys to select either 0V to +5V (C0),
or 0V to +10V (D0). The Default is 0V to +5V.
Group 3
Group Select Parameter
Key Select Key
F#2
F#2
F#2
F#2
F#2
F#2
Sync Enable
Button Blinks
D#0 3 x / 2 x
F#0 3 x / 3 x
G#0 3 x / 4 x
A#0 3 x / 5 x
C#1 3 x / 6 x
D#1 3 x / 7 x
