Operation; Hand Gun Spraying; Boom Spraying - C-Dax GoldLine Series Owner's Manual

Three point linkage sprayers
Table of Contents

Advertisement

Hand Gun Spraying

-
Add chemical mix into the tank at handgun spraying rates recommended on chemical container
-
Ensure control unit pressure control knob is wound fully out (CCW) and dump valve set to 0 (dump
position)
-
Run pump at 540 rpm
-
Ensure fluid flows in return line to tank
-
Turn dump valve lever on control unit to I (pressure position)
-
Set Control unit pressure to required handgun setting.
To prevent damage to pump and control unit, do not exceed recommended maximum rated pressure on the
-
Open valve to hand gun, and allow fluid to flow until all air is expelled from spray line
-
When spraying has finished, turn dump valve lever on control unit to 0 (dump position), and control unit
pressure control is wound fully out (CCW)
-
Proceed with rinsing procedures
To prevent premature failure of drive shaft, DO NOT use drive shaft for heavy-duty equipment. Drive Shaft is
To prevent premature failure of driveshaft, DO NOT exceed 15 angle above or below horizontal on drive shaft
To prevent premature failure of spray pump diaphragms, pump speed MUST BE set at 550 RPM during
If you are using a Geoline Electric control unit, ensure all compensating valves are closed during handgun
operation. Take note of each valve's position and return them to this position once hand gun spraying is
To prevent premature failure of spray pump diaphragms, pump speed MUST BE set at 550 RPM during

operation.

Boom Spraying

-
Add chemical mix into the tank at pressure nozzle spraying rates recommended on chemical container
-
Ensure control unit pressure control knob is wound fully out (CCW) and dump valve set to 0 (dump
position)
-
Run pump at 540 rpm
-
Ensure fluid flows in return line to tank
-
Turn dump valve lever on control unit to I (pressure position)
-
Set Control unit pressure to required pressure setting (nominally 1-4 Bar (15-60psi)).
To prevent damage to pump and control unit, do not exceed recommended maximum rated pressure on the
To allow the spraying system to operate effectively, any spraying device should not exceed 2/3 of the maximum
Example:
2.5 L/min x 12 nozzles = 30 L/min. 30 litres is more than 2/3 the capacity of the M35 pump so an
-
Open valve/s to boom, and allow fluid to flow until all air is expelled from spray lines
-
When spraying has finished, turn dump valve lever on control unit to 0 (dump position), and control unit
pressure control is wound fully out (CCW)
-
Proceed with rinsing procedures
OPERATION
WARNING
spraying components.
WARNING
rated 16hp only (conforming to ISO 5674).
WARNING
during operation.
WARNING
operation.
NOTE
complete.
WARNING
spraying components.
CAUTION
flow of the spray pump.
M50 would be required, or the nozzle flow reduced.
11
