Installation
4.4
Detaching Components from the DataRail
Warning: All live wiring connections and power must be safely disconnected before taking any
components off the DataRail or Wireless I/O System!
1. The End Terminal Bracket can be removed from the DIN rail by inserting the
tip of a flathead screwdriver into the removal slot. Control the direction with
the screwdriver handle to pull the latch away from the DIN rail.
2. Wireless I/O Modules can be removed from the DIN rail by inserting the tip of
a flathead screwdriver into removal slot located on the metal clip. Lift-up on
the screwdriver handle to pull the spring-loaded clip away from the DIN rail.
ProSoft Technology, Inc.
June 10, 2015
Page 21 of 36
