Specifications

3 Specifications
3.1

Hardware and System

HARDWARE & SYSTEM
Unique Features
Maximum Network Capacity*
Power Budget Calculator
Data Encoding Method
I/O Module Slave ID Selection
DIN Rail Mounting Compatibility
DataRail™ (Included w/ Kit)
Auto-Detection of Modules
DataRail Mounting Hardware
Built-In Mounting Hardware
Wire Gauge
Wire Rating
Warranty
3.2

Safety and Compliance

SAFETY & COMPLIANCE
Operational Temperature
Ambient Temperature
Humidity
Degree of Protection / Housing Type
Hazardous Locations Classifications
ProSoft Technology, Inc.
June 10, 2015
Works with Any Modbus RS485 Master Device
No Software Configuration Required
Single Point Power Termination
System can support up to sixteen (16) Digital Modules max
System can support up to eight (8) 0-10 V Modules max
System can support up to five (5) 4-20 mA Modules max
When adding more than five (5) I/O Modules and creating different
I/O Module combinations, please determine maximum allowable I/O
Module combination per system by utilizing the power budget
calculator.
http://psft.com/A7U
MSB First
16-Position Rotary Switch (+1 for Modbus Slave ID)
35 mm x 7.5 mm DIN Rail
6.1" / 156 mm - Supports Up to Exp. + 5x I/O Modules
Yes, via DataRail at Power-Up
4-Claw Attachment to 35 mm DIN Rail with End Terminal Bracket
Spring-Loaded Clip-On System
Solid / Stranded (AWG) 28-12 Gauge
UL: 300 V RMS, 80 °C and 300 V, 105 °C
CSA: 300 V RMS, 105 °C
2-Year Limited
RADIO
-40 °C to 85 °C / -40 °F to 185 °F
-20 °C to 85 °C / -4 °F to 185 °F
0 to 99 %, Non-condensing
IP20 / Plastic
Class I; Division 2 (Zone 2), Pending
Page 11 of 36
