Rs485 Expansion I/O Module; Digital I/O Module - ProSoft Technology RS485 User Manual

3.3

RS485 Expansion I/O Module

RS485 Expansion I/O Module
Baud Rate
Data Bits
Parity / Stop Bits
RS485 Modbus Slave Addressing
Red LED (Left)
Green LED (Right)
Supply Voltage Range
Protection Against Polarity
Power Consumption
Packaging Dimensions (WxHxD)
Net Dimensions (WxHxD)
Packaging Weight
Net Weight
3.4

Digital I/O Module

Digital I/O Module
Number of Inputs
Number of Outputs
Isolation Voltage
Input Voltage Range
Input Voltage Threshold
Output Rating
Green LEDs
Red LEDs
Power Consumption
Packaging Dimensions
Net Dimensions
Packaging Weight
Net Weight (Single)
Page 12 of 36
9600 bits per second
8
None / 1
Interface Supports up to 16 Addresses / I/O Modules*
Power
USB-Ready (For Firmware Update)
9 - 30 VDC (± 5 %)
Yes
Typical: 20 mA / Max: 24 mA @12 VDC
5.5 x 10.1 x 2.8-in / 140 x 257 x 72mm
0.7 x 3.9 x 4.5-in / 17.5 x 99 x 114mm
0.8 lbs / 363 g
0.3 lbs / 136 g
4
4
2500 V r.m.s.
3-30 VDC
1 Signal ("H"): > 2.3 VDC
0 Signal ("L"): < 1.1 VDC
1 A Sink Current for Open-Drain Outputs / NPN
Input Indicators
Output Indicators
Typical: 18 mA / Max: 26 mA @12 VDC
(WxHxD) 4.8 x 5.1 x 2.8-in / 123 x 129 x 72mm
0.7 x 3.9 x 4.5-in / 17.5 x 99 x 114mm
Single: 0.5 lbs / 227 g; Double: 0.8 lbs / 363 g
0.3 lbs / 136 g
Specifications
ProSoft Technology, Inc.
June 10, 2015
